Datasensing QXC/A0-2F Sensors
Datasensing
$198.73
The Datasensing QXC/A0-2F Sensors are advanced photoelectric sensors designed for precision and reliability. Featuring a retroreflective function with a nominal sensing distance of 5 meters, these sensors are equipped with axial and right-angle optics for versatile application. The sensors boast a fast response time of 0.75-0.5 ms and a high switching frequency of 750Hz, ensuring quick and accurate detection. With NPN-PNP selectable output and a high output current capacity of over 300 mA, they are suitable for various industrial environments.
The sensors are designed with user-friendly features such as a trimmer for sensitivity adjustment and LED indicators for output status and stability. They operate efficiently within a voltage range of 10 to 30VDC, with a low no-load supply current of ? 20mA. Built to withstand challenging conditions, they offer short-circuit and reverse polarity protection, and are resistant to external light interference up to 10,000 lux.
Constructed with durable ABS housing and an acrylic active head, the sensors are compact with dimensions of 15x23x40 mm and weigh just 70g. They are rated IP65 for mechanical protection, making them suitable for use in environments with dust and water exposure. The sensors come with ST70 mounting brackets and screws for easy installation, and are compliant with CE and EMC standards, ensuring high performance and safety.
- Nominal sensing distance:
- 5m
- Repeat Accuracy:
- ? 5%
- Sensitivity adjustment:
- Trimmer
- Function Principle:
- Retro-reflector
- Optic position:
- Radial 90°
- Output type:
- NPN/PNP Selectable NO
- Output Function:
- NO
- Switching frequency:
- 750Hz
- Response time:
- 666µs
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 20mA
- Load current:
- ?300mA
- Leakage current:
- ? 100?A @ 30Vdc
- Output voltage drop:
- ?1,2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Red(output status) , Geen (stability)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Infrared (880nm)
- Interference to external light:
- 3000lux Incandescent Lamp, 10000lux
- Dimensions:
- 15x23x57
- Weight:
- 70g
- Connections:
- M8 plug 4pin
- Active Head Material:
- Acrylic
- Operating temperature:
- - 25°C + 70°C ( without freeze)
- Material:
- ABS
- Diameter/Dimension:
- Cubic
- Approvals:
- CE
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-28
- Degree of protection:
- IP65
- Supplied Accessories:
- ST70 mounting brakets and screws
- Dimensions:
- 15x23x40
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP65
- 2D Files:
- View
- 3D Files:
- View
- CAD Files:
- View
- EU Declarations:
- View
- Catalog:
- View
