Datasensing QXP/C0-2E Sensors
Datasensing
$201.18
The Datasensing QXP/C0-2E Sensors are advanced photoelectric sensors designed for precision and reliability. Featuring a polarized function principle, these sensors offer a nominal sensing distance of 3 meters with a repeat accuracy of ? 5%. The sensors are equipped with axial and right-angle optics, providing flexibility in installation. They utilize visible red light in retro-reflective, polarized, and through-beam models, ensuring long-distance capability and a precision beam.
With a fast response time of 0.75-0.5 ms and a switching frequency of 750Hz, these sensors are ideal for high-speed applications. The NPN-PNP selectable output allows for versatile integration into various systems, while the high output current of over 300 mA ensures robust performance. The sensors feature two LED indicators: a red LED for output status and a green LED for stability, providing clear visual feedback.
Built with durability in mind, the sensors have a housing made of ABS material and an active head made of acrylic, offering protection against harsh environments. They are designed to operate within a temperature range of -25°C to +70°C without freezing and have a degree of protection rated at IP65. The sensors are also equipped with short-circuit and reverse polarity protection, ensuring safe and reliable operation.
The compact cubic design, with dimensions of 15x23x40 mm and a weight of 70g, makes these sensors easy to install in tight spaces. They come with an M12 plug for secure connections and are supplied with ST70 mounting brackets and screws for convenient setup. The Datasensing QXP/C0-2E Sensors are CE approved and comply with EMC compatibility standards EN 60947-5-2, making them a reliable choice for various industrial applications.
- Nominal sensing distance:
- 3m
- Repeat Accuracy:
- ? 5%
- Sensitivity adjustment:
- Trimmer
- Function Principle:
- Polarized
- Optic position:
- Radial 90°
- Output type:
- NPN/PNP Selectable NC
- Output Function:
- NC
- Switching frequency:
- 750Hz
- Response time:
- 666µs
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 20mA
- Load current:
- ?300mA
- Leakage current:
- ? 100?A @ 30Vdc
- Output voltage drop:
- ?1,2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Red(output status) , Geen (stability)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Red (660nm)
- Interference to external light:
- 3000lux Incandescent Lamp, 10000lux
- Dimensions:
- 15x23x74
- Weight:
- 70g
- Connections:
- M12 plug
- Active Head Material:
- Acrylic
- Operating temperature:
- - 25°C + 70°C ( without freeze)
- Material:
- ABS
- Diameter/Dimension:
- Cubic
- Approvals:
- CE
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-28
- Degree of protection:
- IP65
- Supplied Accessories:
- ST70 mounting brakets and screws
- Dimensions:
- 15x23x40
- Operating Temperature:
- - 15°C...+ 55°C (Without freeze)
- Mechanical Protection:
- IP65
