Datasensing QXP/C0-1A Sensors

The Datasensing QXP/C0-1A Sensors are designed for precision and reliability in various industrial applications. Featuring a photoelectric sensor with a polarized function principle, these sensors offer a nominal sensing distance of 3 meters and a repeat accuracy of ? 5%. The axial optic position is complemented by a 2-meter PVC cable, ensuring flexibility in installation. Equipped with two LED indicators, the sensor provides clear output status and stability feedback. The visible red light emission at 660nm enhances detection capabilities, even in challenging environments with interference from external light sources up to 10,000 lux. The sensor's fast response time of 666µs and a switching frequency of 750Hz ensure quick and accurate performance. The QXP/C0-1A model supports NPN/PNP selectable output with an NC output function, offering versatility in integration. It operates efficiently within a voltage range of 10 to 30VDC, with a no-load supply current of ? 20mA and a load current capacity of ? 300mA. The sensor is designed with robust protection features, including short-circuit and reverse polarity protection, and maintains a high degree of mechanical protection with an IP65 rating. Constructed with durable ABS housing and an acrylic active head, the sensor withstands operating temperatures from -25°C to +70°C without freezing. The compact cubic design, measuring 15x23x40mm and weighing 70g, allows for easy installation in tight spaces. The package includes ST70 mounting brackets and screws for secure attachment. Compliant with CE approvals and EMC compatibility standards (EN 60947-5-2), the Datasensing QXP/C0-1A Sensors are engineered to endure shocks and vibrations as per IEC standards, making them a reliable choice for demanding industrial environments.
