Datasensing QXR/A0-1A Sensors
Datasensing
$184.00
The Datasensing QXR/A0-1A Sensors are designed for precision and reliability in demanding environments. Featuring axial and right-angle optics, these photoelectric sensors offer a nominal sensing distance of 8 meters with a repeat accuracy of ? 5%. The sensors are equipped with two LED indicators for threshold and signal margin, providing clear visibility with a red light in retro-reflective, polarized, and through-beam models.
With a fast response time of 0.75-0.5 ms and a switching frequency of 500Hz, these sensors ensure quick and accurate detection. The NPN-PNP selectable output allows for flexible integration into various systems, while the high output current capability of over 300 mA ensures robust performance.
The QXR/A0-1A sensors are built to withstand harsh conditions, featuring short-circuit and reverse polarity protection, and are EMC compatible with EN 60947-5-2 standards. The durable ABS housing and IP65 mechanical protection make them suitable for industrial applications, withstanding operating temperatures from -25°C to +70°C.
Supplied with ST70 mounting brackets and screws, these sensors are easy to install and maintain. The 2m PVC cable connection and acrylic active head material further enhance their durability and performance. Ideal for applications requiring long-distance sensing and precision, the Datasensing QXR/A0-1A Sensors are a reliable choice for your automation needs.
- Nominal sensing distance:
- 8m
- Repeat Accuracy:
- ? 5%
- Sensitivity adjustment:
- Trimmer
- Function Principle:
- Receiver
- Optic position:
- Axial
- Output type:
- NPN/PNP Selectable NO
- Output Function:
- NO
- Switching frequency:
- 500Hz
- Response time:
- 1ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 5mA
- Load current:
- ?300mA
- Leakage current:
- ? 100?A @ 30Vdc
- Output voltage drop:
- ?1,2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Red(output status) , Geen (stability)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Interference to external light:
- 3000lux Incandescent Lamp, 10000lux
- Dimensions:
- 15x23x76
- Weight:
- 70g
- Connections:
- 2m PVC cable
- Active Head Material:
- Acrylic
- Operating temperature:
- - 25°C + 70°C ( without freeze)
- Material:
- ABS
- Diameter/Dimension:
- Cubic
- Approvals:
- CE
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-28
- Degree of protection:
- IP65
- Supplied Accessories:
- ST70 mounting brakets and screws
- Dimensions:
- 15x23x40
- Operating Temperature:
- - 15°C...+ 55°C (Without freeze)
- Mechanical Protection:
- IP65
