Datasensing RXR/00-3B Sensors
Datasensing
$146.27
The Datasensing RXR/00-3B Sensors are advanced photoelectric sensor receivers designed for versatile applications. With a selectable nominal sensing distance of 16-32 meters, these sensors offer high performance in a compact form. They feature a relay output with SPST NO/NC function and a multifunctional DECOUT® system, providing flexibility in various operational settings. The sensors are equipped with a timer function that includes delay on, delay off, and one-shot capabilities, along with a trimmer for sensitivity adjustment.
For precise detection, the through-beam types include a switch to reduce emission, and the LED alignment indicator offers 360° visibility with two LED indicators for stable signal and output status. The M12 standard plug cable exit, along with axial and right-angle brackets, ensures easy installation.
Operating on a wide voltage range of 20...60VDC / 20...253VAC/50-60Hz, these sensors are built to withstand harsh conditions with an operating temperature range of -25°C to +70°C and a degree of protection rated at IP65. The housing is made of durable PC material, and the active head is crafted from PMMA, ensuring longevity and reliability.
Additional features include reverse polarity protection, impulsive overvoltage protection, and high resistance to external light interference. The sensors are CE approved and comply with EMC compatibility standards EN 60947-5-2, ensuring they meet rigorous safety and performance criteria. Supplied with an ST81 mounting bracket and screws, the Datasensing RXR/00-3B Sensors are an ideal choice for applications requiring precise and reliable photoelectric sensing.
- Nominal sensing distance:
- 16-32m selectable with switch
- Thermal drift of Sr:
- 10% Sr
- Repeat Accuracy:
- 5%
- Function Principle:
- Receiver
- Optic position:
- Axial
- Output type:
- Relay SPST NO/NC
- Output Function:
- NO/NC
- Switching frequency:
- 25Hz
- Response time:
- 20ms
- Operating Voltage:
- 20...60VDC /20...253VAC/50-60Hz
- No-Load supply current:
- ? 30mARMS
- Load current:
- 3A-250Vac/3A-30Vdc (750VA/90W)
- Max ripple content:
- ?10%
- LED indicators:
- Red (output status) o (alineament), Green (stability)
- Time delay before availability:
- ?200ms
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Infrared (880nm)
- Interference to external light:
- ? 10000lux (incandescent lamp)
- Impulsive Overvoltage Protection:
- Yes
- Weight:
- 90g
- Housing Material:
- PC
- Connections:
- M12 plug
- Active Head Material:
- PMMA
- Operating temperature:
- - 25°C + 70°C ( without freeze)
- Diameter/Dimension:
- Cubic
- Approvals:
- CE
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-28
- Degree of protection:
- IP65
- Supplied Accessories:
- ST81 mounting bracket and screws
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP65
