Interface Electronic
Modern equipment design requires a wide variety of components that can meet diverse challenges: Examples include user- and maintenance-friendliness, low investment costs, safety and availability, and simplicity in design and usage.
Different WAGO Interface Modules with various designs, such as pluggable function and interface modules, narrow relay and optocouplers and modern high-efficiency switch mode power supplies, are ideal for meeting these challenges and ensuring safe isolation of the wiring and function levels.
-
WAGO 788-541
Wago
$25.41Socket with miniature switching relay; Relay with 1 changeover contact (1u); 24 VAC; electrical and mechanical status indication; manually operated Reinforced insulation between coil and contacts ...788-541$25.41 -
WAGO 788-516
Wago
$24.12Relay socket with relay and status indicator; each 2 changeover contacts (2u); 230 VAC Reinforced insulation between coil and contacts A separator plate (e.g., 209-191) must be used...788-516$24.12 -
WAGO 788-515
Wago
$24.12Relay module; Nominal input voltage: 115 VAC; 2 changeover contacts; Limiting continuous current: 8 A; Red status indicator; Module width: 15 mm; 2,50 mm²; gray. The WAGO 788 series plug-in relay assembly features a socket base with a red LED indicator...788-515$24.12 -
WAGO 788-512
Wago
$21.03Relay module; Nominal input voltage: 24 VAC; 2 changeover contacts; Limiting continuous current: 8 A; Red status indicator; Module width: 15 mm; 2,50 mm²; gray. The WAGO 788 series plug-in relay assembly features a socket base with a red LED indicator...788-512$21.03 -
WAGO 788-508
Wago
$23.18Relay module; Nominal input voltage: 230 VAC; 1 changeover contact; Limiting continuous current: 16 A; Red status indicator; Module width: 15 mm; 2,50 mm²; gray. The WAGO 788 series plug-in relay assembly features a single-pole (1P) design with a...788-508$23.18 -
WAGO 788-507
Wago
$20.34Relay module; Nominal input voltage: 115 VAC; 1 changeover contact; Limiting continuous current: 16 A; Red status indicator; Module width: 15 mm; 2,50 mm²; gray. The WAGO 788 series plug-in relay assembly features a single-pole (1P) design with a...788-507$20.34 -
WAGO 788-506
Wago
$17.52Relay socket with relay and status indicator; each 1 changeover contact (1 u); 24 VAC Reinforced insulation between coil and contacts A separator plate (e.g., 209-191) must be used...788-506$17.52 -
WAGO 788-412
Wago
$28.70Relay socket with relay and status indicator; 24 VDC Reinforced insulation between coil and contacts A separator plate (e.g., 209-191) must be used for voltages greater than 250 V...788-412$28.70 -
WAGO 788-404
Wago
$26.86Relay module; Nominal input voltage: 24 VDC; 1 changeover contact; Limiting continuous current: 16 A; with gold contacts; Red status indicator; Module width: 15 mm; 2,50 mm²; gray. The WAGO 788 series plug-in relay assembly features a single-pole (1P)...788-404$26.86 -
WAGO 788-391
Wago
$25.14Relay module; Nominal input voltage: 24 VDC; 1 changeover contact; Limiting continuous current: 16 A; with manual operation; Railway; Red status indicator; Module width: 15 mm. The WAGO 788 series plug-in relay assembly features a socket base, manual...788-391$25.14 -
WAGO 788-390
Wago
$26.86Socket with miniature switching relay; Relay with 2 changeover contacts (2u); 24 VDC; electrical and mechanical status indication; for railway operations Reinforced insulation between coil and contacts ...788-390$26.86 -
WAGO 788-384
Wago
$55.30Relay module with driven contacts; Nominal input voltage: 24 VDC; 2 changeover contacts; Limiting continuous current: 6 A; Red status indicator; Module width: 15 mm; 2,50 mm²; gray. The WAGO 788 series plug-in relay assembly features a socket base with...788-384$55.30 -
WAGO 788-357
Wago
$29.10Relay module; Nominal input voltage: 24 VDC; 1 make contact; Limiting continuous current: 16 A; Red status indicator; Module width: 15 mm. The WAGO 788 series plug-in relay assembly features a single-pole, normally open (1NO/SPST-NO) electromechanical...788-357$29.10 -
WAGO 788-356
Wago
$26.46Relay module; Nominal input voltage: 24 VDC; 1 make contact; Limiting continuous current: 16 A; for lamp loads; Red status indicator; Module width: 15 mm. The WAGO 788 series plug-in relay assembly features a single-pole, normally open (1NO/SPST-NO)...788-356$26.46 -
WAGO 788-355
Wago
$25.14Relay module; Nominal input voltage: 24 VDC; 1 make contact; Limiting continuous current: 16 A; for lamp loads; Red status indicator; Module width: 15 mm; 2,50 mm²; gray. The WAGO 788 series plug-in relay assembly features a single-pole, normally open...788-355$25.14 -
WAGO 788-354
Wago
$27.26Relay module; Nominal input voltage: 24 VDC; 1 changeover contact; Limiting continuous current: 16 A; for lamp loads; Red status indicator; Module width: 15 mm; 2,50 mm²; gray. The WAGO 788 series plug-in relay assembly features a single-pole,...788-354$27.26 -
WAGO 788-349
Wago
$29.37Socket with miniature switching relay; Relay with 2 changeover contacts (2u); 110 VDC; electrical and mechanical status indication; manually operated Reinforced insulation between coil and contacts ...788-349$29.37 -
WAGO 788-347
Wago
$27.78Socket with miniature switching relay; Relay with 2 changeover contacts (2u); 48 VDC; electrical and mechanical status indication; manually operated Reinforced insulation between coil and contacts ...788-347$27.78 -
WAGO 788-346
Wago
$26.86Relay module; Nominal input voltage: 24 VDC; 2 changeover contacts; Limiting continuous current: 8 A; with manual operation; Red status indicator; Module width: 15 mm. The WAGO 788 series plug-in relay assembly features a socket base, manual operation,...788-346$26.86 -
WAGO 788-344
Wago
$27.78Relay module; Nominal input voltage: 110 VDC; 1 changeover contact; Limiting continuous current: 16 A; with manual operation; Red status indicator; Module width: 15 mm. The WAGO 788 series plug-in relay assembly features a socket base, manual operation,...788-344$27.78
