Relays and Optocouplers
Whether relay sockets or pluggable relay and optocoupler modules, WAGO's array of relays and optocouplers offer a solution for any requirement. Use them in any sector of industry including process technology and power engineering, railway applications and machine engineering, as well as general control cabinet construction.
-
WAGO 858-154 Pack of 3
$30.18Description Pluggable industrial relay; 24 VAC Remarks Item properties Miscellaneous Name Value Unit Pull-in time (typ.) [ms] 25 ms Drop-out time (typ.) [ms] 25 ms ...858-154$30.18 -
Wago 858-153 Pluggable industrial relay
$1.00Basic relay; Nominal input voltage: 230 VAC; 4 changeover contacts; Limiting continuous current: 5 A; with gold contacts; with manual operation; Module width: 22 mm; Module height: 25 mm858-153$1.00 -
WAGO 858-152 Pack of 3
$37.29Description Pluggable industrial relay; 24 VDC Remarks Note:*To prevent the gold layer from being damaged, 30 VDC switching voltages and 50 mA currents shall not be exceeded. Higher switching power eventually evaporates the gold layer...858-152$37.29 -
WAGO 858-151 Pack of 3
$30.18Description Pluggable industrial relay; AC 240 V Remarks Item properties Miscellaneous Name Value Unit Pull-in time (typ.) [ms] 25 ms Drop-out time (typ.) [ms] 25 ms ...858-151$30.18 -
WAGO 858-150 Pack of 3
$27.21Basic relay; Nominal input voltage: 24 VDC; 4 changeover contacts; Limiting continuous current: 5 A; with manual operation; Module width: 22 mm; Module height: 25 mm858-150$27.21 -
$6.28
-
WAGO 858-100 Pack of 10
$116.90Relay socket for industrial relays; 2 and 4 changeover contacts; for DIN 35 rail; FRONT-ENTRY; Push-in CAGE CLAMPConnection; HORIZONTAL TYPE858-100$116.90 -
WAGO 857-728
$55.13Solid-state relay module; Nominal input voltage: 230 V AC/DC; Output voltage range: 0 30 VDC; Limiting continuous current: 3 A; 2-wire connection; Yellow status indicator; Module width: 6 mm; gray857-728$55.13 -
WAGO 857-727
$53.18Solid-state relay module; Nominal input voltage: 115 V AC/DC; Output voltage range: 0 30 VDC; Limiting continuous current: 3 A; 2-wire connection; Yellow status indicator; Module width: 6 mm; gray857-727$53.18 -
WAGO 857-724
$49.53Socket with solid state relay; Input: 24 V DC; Output DC 0 V ... 24 V / 2 A Technical Data Nominal input voltage U<sub>N</sub>: DC 24 V ...857-724$49.53 -
WAGO 857-718
$56.35Solid-state relay module; Nominal input voltage: 230 V AC/DC; Output voltage range: 24 240 VAC; Limiting continuous current: 2 A; 2-wire connection; zero-cross switching; Yellow status indicator; Module width: 6 mm; gray857-718$56.35 -
WAGO 857-717
$55.62Solid-state relay module; Nominal input voltage: 115 V AC/DC; Output voltage range: 24 240 VAC; Limiting continuous current: 2 A; 2-wire connection; zero-cross switching; Yellow status indicator; Module width: 6 mm; gray857-717$55.62 -
WAGO 857-714
$49.40Solid-state relay module; Nominal input voltage: 24 VDC; Output voltage range: 24 240 VAC; Limiting continuous current: 2 A; 2-wire connection; zero-cross switching; Yellow status indicator; Module width: 6 mm; gray857-714$49.40 -
WAGO 857-708
$44.16Socket with solid state relay; Input AC/DC 230 V; Output DC 0 V ... 48 V / 0.1 A Technical Data Nominal input voltage U<sub>N</sub>: ...857-708$44.16 -
WAGO 857-707
$42.08Socket with solid state relay; Input AC/DC 115 V; Output DC 0 V ... 48 V / 0.1 A Technical Data Nominal input voltage U<sub>N</sub>: ...857-707$42.08 -
WAGO 857-704
$35.00Technical Data Nominal input voltage U<sub>N</sub>: DC 24 V Input voltage range (low level): DC 0 10 V ...857-704$35.00 -
WAGO 857-642
$186.10Multifunction timing relay with 1 changeover contact (1u); 8 tiem ranges; 7 functions; 2 adjustable time ranges; Temperature range: -25 C ... +70 C; for railway operations 7 functions ...857-642$186.10 -
WAGO 857-640
$169.50Multifunction timing relay with 1 changeover contact (1u); 8 tiem ranges; 14 functions; Temperature range: -25 C ... +70 C; for railway operations 14 functions Function and time range...857-640$169.50 -
WAGO 857-634
$100.00Multifunction timing relay with solid state relay; each 1 make contact (1a); 4 time ranges; 4 functions; Switching voltage: 24 V ... 230 VDC 4 functions Function and time range...857-634$100.00 -
WAGO 857-624
$100.00Solid-state timer relay module; Nominal input voltage: 24 VDC; Output voltage range: 0 24 VDC; Limiting continuous current: 2 A; 2-wire connection; Multifunction/Multitime; Yellow status indicator; Module width: 6 mm857-624$100.00
