Description
Linergy NEMA fuse holders are panel mount fuse holders that will accept class H, R, CC, M, and J fuses up to 200 Amps. This three pole fuse holder will accept class R fuses. The rating of the fuse can be up to 100 Amps with a 600 V maximum rating. These thermal units will trip in 20 seconds or less on overload conditions. Fuse clips are made of one piece aluminum with copper spring that is tin plated. The fuse clips are reinforced for a better connection. The fuse holder base is made of general purpose phenolic. AIC Rating in accordance with UL512 is 20,000 Amp. This fuse holder is UL listed and CSA certified.
