Schneider Electric EDB16050 Mini circuit breaker, E-Frame, 50A, 1 pole, 600Y/347VAC, 25kA max, bolt on

(No reviews yet) Write a Review

Write a Review

Schneider Electric

Schneider Electric EDB16050 Mini circuit breaker, E-Frame, 50A, 1 pole, 600Y/347VAC, 25kA max, bolt on

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

EDB16050

UPC:

MPN:

EDB16050

Condition:

New

Eu Rohs Directive:

Pro-active compliance (Product out of EU RoHS legal scope)

Mercury Free:

Yes

Breaking Capacity:

14 kA 600Y/347 V AC

Awg Gauge:

AWG 12...AWG 2/0 aluminium || AWG 14...AWG 2/0 copper

Tightening Torque:

3.9-3.9 N.m 2.5-6 mm² (AWG 14...AWG 10) || 5.6-5.6 N.m 10-70 mm² (AWG 8...AWG 2/0)

Local Signaling:

trip indicator

Number Of Spaces Required:

1

Number Of Spaces:

1

Device Short Name:

EDB

Trip Unit Technology:

thermal-magnetic

Line Rated Current:

50 A

China Rohs Regulation:

Product out of China RoHS scope. Substance declaration for your information.

Protection Type:

overload || short-circuit

Reach Regulation:

Reference contains Substances of Very High Concern above the threshold

Ambient Air Temperature For Operation:

40°C

Product Destination:

NF panelboard

Circuit Breaker Application:

HACR rated

Weight:

2 lb(US)

Breaking Capacity Code:

D

[Ue] Rated Operational Voltage:

600Y/347 V AC

Module Type:

E-Frame

Holding Current:

630 A

Rohs Exemption Information:

Yes

Country of Origin:

Mexico

Mounting Mode:

bolt-on

Warranty:

18 months

Net Weight:

2 lb(US)

Number Of Poles:

1

Depth:

4.05 in

Trip Unit Rating:

1800-1800 A

Electrical Connection:

lugs aluminium

Product Or Component Type:

circuit-breaker

Range Of Product:

125 A Frame EDB-EGB-EJB

Product Certifications:

cULus || IEC
