Schneider Electric EGB34100AABA Mini circuit breaker, E-Frame, 100A, 3 pole, 480Y/277VAC, 65kA max, bolt on, aux switch, alarm switch
Schneider Electric
$1,604.00
(No reviews yet)
Write a Review
Write a Review
Schneider Electric
Schneider Electric EGB34100AABA Mini circuit breaker, E-Frame, 100A, 3 pole, 480Y/277VAC, 65kA max, bolt on, aux switch, alarm switch
E-Frame Breaker are Lighting Panelboard Circuit breakers that are proven effective and reliable which provide a wide variety or robust features that are use specifically in Square D NF Panelboards. This range of breaker is ideally designed to offer superior overload and short circuit protection. All E-Frame breakers have a thermal-magnetic trip unit as well as signal indicator that will indicate when a trip has occur. Mounting bolts are used to hold these breakers in place. This E-Frame breaker is 100A, 3 pole, and has an operating voltage of 480Y/277 VAC. It also provides a 65 kA max interrupt rating at 120 VAC. This device has a hold current of 1000A which is the maximum current the breaker can be held to ensure it will trip and a trip current of 2300A which is the current value when the breaker is guaranteed to trip. Many accessories are available for this breaker. This one includes an auxiliary switch and an alarm switch. This breaker was calibrated for 40 degrees C. HACR rated.
- Product Destination:
- NF panelboard
- Electrical Connection:
- lugs aluminium
- Module Type:
- E-Frame
- Mounting Mode:
- bolt-on
- Range Of Product:
- 125 A Frame EDB-EGB-EJB
- Weight:
- 4 lb(US)
- Breaking Capacity Code:
- G
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
- Number Of Spaces:
- 4
- Product Certifications:
- cULus
- Depth:
- 4.05 in
- Product Or Component Type:
- miniature circuit-breaker
- Trip Unit Technology:
- thermal-magnetic
- Mercury Free:
- Yes
- Number Of Spaces Required:
- 4
- Protection Type:
- overload || short-circuit
- Number Of Poles:
- 3
- Local Signaling:
- trip indicator
- Tightening Torque:
- 3.9-3.9 N.m 2.5-6 mm² (AWG 14...AWG 10) || 5.6-5.6 N.m 10-70 mm² (AWG 8...AWG 2/0)
- Circuit Breaker Application:
- HACR rated
- Breaking Capacity:
- 35 kA 277 V AC || 65 kA 240 V AC || 35 kA 480Y/277 V AC || 65 kA 120 V AC || 65 kA 120/240 V AC
- Eu Rohs Directive:
- Compliant with Exemptions
- Holding Current:
- 1000 A
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Trip Unit Rating:
- 2300-2300 A
- Line Rated Current:
- 100 A
- Country of Origin:
- Mexico
- Device Composition:
- alarm switch || auxiliary switch
- Net Weight:
- 4 lb(US)
- [Ue] Rated Operational Voltage:
- 480Y/277 V AC
- Ambient Air Temperature For Operation:
- 40°C
- Rohs Exemption Information:
- Yes
- Awg Gauge:
- AWG 12...AWG 2/0 aluminium || AWG 14...AWG 2/0 copper
- Device Short Name:
- EGB
