Schneider Electric

Schneider Electric GB2CB05 TeSys GB2 thermal magnetic circuit protector, 1 P, 0.5 A, Id = 6.6 A

(No reviews yet) Write a Review
SKU:
GB2CB05
MPN:
GB2CB05
Condition:
New
Environmental Disclosure:
ENVPEP2306023
9 Mm Pitches:
2
Utilisation Category:
category A IEC 60947-2 || DC-12 IEC 60947-5-1 || DC-13 IEC 60947-5-1
Mounting Position:
horizontal || vertical
Network Type:
AC/DC
Reach Regulation:
Free of Substances of Very High Concern above the threshold
Warranty:
18 months
Standards:
EN/IEC 60947-1 || EN/IEC 60947-2 || CSA C22.2 No 235 || UL 1077
Breaking Capacity:
50 kA Icu 110 V AC 50/60 Hz IEC 60947-2 || 50 kA Icu 230/240 V AC 50/60 Hz IEC 60947-2 || 1.5 kA Icu 24 V DC IEC 60947-2 || 1 kA Icu 48 V DC IEC 60947-2
Sustainable Offer Status:
Green Premium product
Tightening Torque:
1.2 N.m connector
Connections - Terminals:
connector 1 0.75-6 mm²solid without cable end || connector 2 0.75-4 mm²solid without cable end || connector 1 0.75-4 mm²flexible with cable end || connector 2 0.75-2.5 mm²flexible with cable end
Ambient Air Temperature For Operation:
-20-60°C
Power Dissipation Per Pole:
2 W
Mechanical Durability:
8000 cycles
Ambient Air Temperature For Storage:
-40-80°C
Country of Origin:
United States
Mounting Support:
plate || rail
Poles Description:
1P
Range:
TeSys
Device Application:
control
Weee:
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Reach Free Of Svhc:
Yes
Magnetic Tripping Current:
6.6-6.6 A
Network Frequency:
50/60 Hz IEC 60947-2
Control Type:
toggle
Product Certifications:
UL || CSA
Protective Treatment:
TC
Trip Unit Technology:
thermal-magnetic
Line Rated Current:
0.5 A
Eu Rohs Directive:
Compliant
California Proposition 65:
WARNING: Cancer - www.P65Warnings.ca.gov
Electrical Durability:
8000 cycles
Fire Resistance:
960°C IEC 60695-2-1
[Ue] Rated Operational Voltage:
250 V AC 50/60 Hz IEC 60947-2 || 277 V AC 60 Hz CSA C22.2 No 235 || 277 V AC 60 Hz UL 1077 || 48 V DC
Rohs Exemption Information:
Yes
Mounting Mode:
by clips
China Rohs Regulation:
Pro-active China RoHS declaration (out of China RoHS legal scope)
Operating Altitude:
9842.52 ft (3000 m)
Quantity Per Set:
set of 6
Product Or Component Type:
circuit breaker
Device Short Name:
GB2
Ip Degree Of Protection:
IP20 IEC 60529
Toxic Heavy Metal Free:
Yes
Mechanical Robustness:
shocks 22 Gn for 20 ms IEC 60068-2-27 || vibrations 5 Gn, 5...110 Hz IEC 60068-2-6
Depth:
67 mm
$43.60

Description

TeSys GB circuit breaker, 1 pole (1P), 0.5A/250V IEC/277V UL, for the protection of industrial equipment control circuits. It provides thermal-magnetic protection with a magnetic tripping level at 6.6A (13 In) and breaking capacity Icu 50kA@240V. It can also be used for protection of DC loads up to 0.5A/48V DC-13 with a breaking capacity Icu 1.5kA@24V. Compact device (15mm wide), mounting on 35mm DIN-rail, control by toggle lever (start-stop guaranteed for 8000 cycles). Sold in lots of 6 units. Multi standards certified (IEC, UL, CSA), Green Premium product (RoHS/REACh).
