Schneider Electric GV4PE07S6 Motor circuit breaker, TeSys GV4, 3P, 7A, Icu 100kA, thermal magnetic, lugs terminals

Schneider Electric GV4PE07S6 Motor circuit breaker, TeSys GV4, 3P, 7A, Icu 100kA, thermal magnetic, lugs terminals

Schneider Electric
SKU:
GV4PE07S6
$1,342.50
(No reviews yet) Write a Review
Condition:
New
Current Stock:
Description
TeSys GV motor circuit breaker, 3 poles (3P), 7A/690V, for protection of 3-phase motors 1.5-3kW@400V. It provides thermal magnetic protection and additional motor protection functions, breaking capacity Icu 100kA@400V, start-stop control by toggle, connection for bars or cables with lugs. Thermal protection adjustable by dials with a setting current Ir in range 2.9-7A and a selectable tripping class 10 or 20, magnetic protection at 17 In. Additional protections have fixed pick-up and include short time delay protection Isd at 13 Ir, phase unbalance and loss protection, ground fault protection. It makes internal locations available for additional auxiliary contact blocks (OF, SD), and voltage trip units (MN, MX). Multi standards certified (IEC, UL, CSA, CCC, EAC, Marine, ATEX), Green Premium compliant (RoHS/REACh).
Additional Information
Ambient Air Temperature For Storage:
-50-85°C
Breaking Capacity:
120 kA Icu 220...240 V AC 50/60 Hz IEC 60947-2 || 100 kA Icu 380...415 V AC 50/60 Hz IEC 60947-2 || 70 kA Icu 440 V AC 50/60 Hz IEC 60947-2 || 30 kA Icu 500 V AC 50/60 Hz IEC 60947-2 || 18 kA Icu 525 V AC 50/60 Hz IEC 60947-2 || 100 kA 208Y/120 V AC
Fire Resistance:
960°C IEC 60695-2-11
Weight:
1.45 kg
Net Weight:
1.45 kg
Power Dissipation Per Pole:
4.6 W
Halogen Content Performance:
Halogen free plastic parts product
Circularity Profile:
ENVEOLI1704004EN
Device Short Name:
GV4PE
Trip Unit Technology:
electronic || thermal-magnetic
Maximum Operating Rate:
25 cyc/h
Poles Description:
3P
Ambient Air Temperature For Operation:
-25-70°C
[Uimp] Rated Impulse Withstand Voltage:
8 kV IEC 60947-2
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Operating Altitude:
5000 m
[Ui] Rated Insulation Voltage:
800 V AC 50/60 Hz IEC 60947-2
Operating Position:
any position
Electrical Durability:
40000 cycles AC-3 440 V In/2 || 40000 cycles AC-3 440 V In
Tightening Torque:
9 N.m 16-95 mm² || 5 N.m 1.5-10 mm²
Product Or Component Type:
motor circuit breaker
Depth:
116 mm
Standards:
CSA C22.2 No 60947-4-1 || UL 60947-4-1 || EN/IEC 60947-4-1 || EN/IEC 60947-2
[Ith] Conventional Free Air Thermal Current:
115 A IEC 60947-4-1
Pvc Free:
Yes
Ip Degree Of Protection:
IP40 IEC 60529
Weee:
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Product Name:
TeSys GV4 || TeSys Deca
Magnetic Tripping Current:
119-119 A
Pollution Degree:
3
Range Of Product:
TeSys GV4
Range:
TeSys Deca
Color:
Gray RAL 7016)
Suitability For Isolation:
yes IEC 60947-1
Utilisation Category:
category A IEC 60947-2 || AC-3 IEC 60947-4-1
Connection Pitch:
27 mm without spreaders || 35 mm with spreaders
[Ue] Rated Operational Voltage:
690 V AC 50/60 Hz IEC 60947-2
Rohs Exemption Information:
Yes
Environmental Disclosure:
ENVPEP1704004EN
Phase Failure Sensitivity:
yes IEC 60947-4-1
Connections - Terminals:
lugs-ring terminals
Mechanical Durability:
40000 cycles
Sustainable Offer Status:
Green Premium product
Mercury Free:
Yes
Product Certifications:
IEC || UL || CSA || CCC || EAC || ATEX || EU-RO MR
Warranty:
18 months
