Schneider Electric GV4PE50N Motor circuit breaker, TeSys GV4, 3P, 50A, Icu 50kA, thermal magnetic, Everlink terminals

(No reviews yet) Write a Review
SKU:
GV4PE50N
MPN:
GV4PE50N
Condition:
New
Electrical Durability:
20000 cycles AC-3 440 V In/2 || 10000 cycles AC-3 440 V In
Ambient Air Temperature For Operation:
-25-70°C
Phase Failure Sensitivity:
yes IEC 60947-4-1
Device Short Name:
GV4PE
Climatic Withstand:
IACS E10
[Ith] Conventional Free Air Thermal Current:
115 A IEC 60947-4-1
Warranty:
18 months
Range Of Product:
TeSys GV4
Net Weight:
1.45 kg
Device Application:
motor protection
Operating Altitude:
5000 m
Ambient Air Temperature For Storage:
-50-85°C
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Pvc Free:
Yes
Ip Degree Of Protection:
IP40 IEC 60529
[Uimp] Rated Impulse Withstand Voltage:
8 kV IEC 60947-2
Maximum Operating Rate:
25 cyc/h
Suitability For Isolation:
yes IEC 60947-1
Weight:
1.45 kg
Poles Description:
3P
Range:
TeSys Deca
Country of Origin:
Poland
Standards:
CSA C22.2 No 60947-4-1 || UL 60947-4-1 || EN/IEC 60947-4-1 || EN/IEC 60947-2
Magnetic Tripping Current:
850-850 A
Circularity Profile:
ENVEOLI1704004EN
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Mechanical Robustness:
vibrations +/- 1 mm 2...13.2 Hz IEC 60068-2-6 || vibrations 0.7 gn 13.2...100 Hz IEC 60068-2-6 || shocks 15 gn 11 ms IEC 60068-2-27
Connections - Terminals:
EverLink BTR screw connectors top) 1 1.5-70 mm² - solid || EverLink BTR screw connectors top) 1 1.5-50 mm² - flexible || EverLink BTR screw connectors bottom) 1 2.5-95 mm² - solid || EverLink BTR screw connectors bottom) 1 2.5-70 mm² - flexible
[Ui] Rated Insulation Voltage:
800 V AC 50/60 Hz IEC 60947-2
[Ue] Rated Operational Voltage:
690 V AC 50/60 Hz IEC 60947-2
Rated Duty:
continuous IEC 60947-4-1
Tightening Torque:
9 N.m 16-95 mm² || 5 N.m 1.5-10 mm²
Depth:
116 mm
Pollution Degree:
3
Mechanical Durability:
40000 cycles
Fire Resistance:
960°C IEC 60695-2-11
Weee:
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Halogen Content Performance:
Halogen free plastic parts product
Utilisation Category:
category A IEC 60947-2 || AC-3 IEC 60947-4-1
Product Certifications:
IEC || UL || CSA || CCC || EAC || ATEX || EU-RO MR
Color:
Gray RAL 7016)
Rohs Exemption Information:
Yes
Line Rated Current:
50 A
Product Name:
TeSys GV4 || TeSys Deca
Breaking Capacity:
100 kA Icu 220...240 V AC 50/60 Hz IEC 60947-2 || 50 kA Icu 380...415 V AC 50/60 Hz IEC 60947-2 || 50 kA Icu 440 V AC 50/60 Hz IEC 60947-2 || 15 kA Icu 525 V AC 50/60 Hz IEC 60947-2 || 65 kA 208Y/120 V AC 50/60 Hz UL 60947 || 65 kA 240 V AC 50/60 Hz
Ik Degree Of Protection:
IK07 IEC 62262
Mercury Free:
Yes
Trip Unit Technology:
thermal-magnetic || electronic
$695.00

Description

TeSys GV motor circuit breaker, 3 poles (3P), 50A/690V, for protection of 3-phase motors 11-22kW@400V. It provides thermal magnetic protection and additional motor protection functions, breaking capacity Icu 50kA@400V, start-stop control by toggle, connection by Everlink BTR screw terminals. Thermal protection adjustable by dials with a setting current Ir in range 20-50A and a selectable tripping class 10 or 20, magnetic protection at 17 In. Additional protections have fixed pick-up and include short time delay protection Isd at 13 Ir, phase unbalance and loss protection, ground fault protection. It makes internal locations available for additional auxiliary contact blocks (OF, SD), and voltage trip units (MN, MX). Multi standards certified (IEC, UL, CSA, CCC, EAC, Marine, ATEX), Green Premium compliant (RoHS/REACh).
