Schneider Electric GV4PE50S Motor circuit breaker, TeSys GV4, 3P, 50A, Icu 100kA, thermal magnetic, Everlink terminals

(No reviews yet) Write a Review
SKU:
GV4PE50S
MPN:
GV4PE50S
Condition:
New
Pollution Degree:
3
Magnetic Tripping Current:
850-850 A
Device Short Name:
GV4PE
Ambient Air Temperature For Operation:
-25-70°C
Range:
TeSys Deca
Poles Description:
3P
Ip Degree Of Protection:
IP40 IEC 60529
Tightening Torque:
9 N.m 16-95 mm² || 5 N.m 1.5-10 mm²
[Ui] Rated Insulation Voltage:
800 V AC 50/60 Hz IEC 60947-2
Weight:
1.45 kg
Breaking Capacity:
120 kA Icu 220...240 V AC 50/60 Hz IEC 60947-2 || 100 kA Icu 380...415 V AC 50/60 Hz IEC 60947-2 || 70 kA Icu 440 V AC 50/60 Hz IEC 60947-2 || 30 kA Icu 500 V AC 50/60 Hz IEC 60947-2 || 18 kA Icu 525 V AC 50/60 Hz IEC 60947-2 || 100 kA 208Y/120 V AC
Phase Failure Sensitivity:
yes IEC 60947-4-1
Range Of Product:
TeSys GV4
Motor Power Kw:
11-11 kW 400...415 V AC 50/60 Hz || 15-15 kW 500 V AC 50/60 Hz || 18.5-18.5 kW 660...690 V AC 50/60 Hz || 15-15 kW 400...415 V AC 50/60 Hz || 18.5-18.5 kW 400...415 V AC 50/60 Hz || 22-22 kW 400...415 V AC 50/60 Hz || 18.5-18.5 kW 500 V AC 50/60 Hz |
Mechanical Durability:
40000 cycles
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Operating Position:
any position
Product Certifications:
IEC || UL || CSA || CCC || EAC || ATEX || EU-RO MR
Utilisation Category:
category A IEC 60947-2 || AC-3 IEC 60947-4-1
Control Type:
toggle
Country of Origin:
Mexico
[Uimp] Rated Impulse Withstand Voltage:
8 kV IEC 60947-2
Circularity Profile:
ENVEOLI1704004EN
Fire Resistance:
960°C IEC 60695-2-11
Halogen Content Performance:
Halogen free plastic parts product
Suitability For Isolation:
yes IEC 60947-1
Pvc Free:
Yes
Eu Rohs Directive:
Compliant with Exemptions
Power Dissipation Per Pole:
4.6 W
Net Weight:
1.45 kg
Height:
155 mm
Rohs Exemption Information:
Yes
Product Name:
TeSys GV4 || TeSys Deca
Width:
81 mm
[Ith] Conventional Free Air Thermal Current:
115 A IEC 60947-4-1
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Color:
Gray RAL 7016)
Trip Unit Technology:
electronic || thermal-magnetic
Rated Duty:
continuous IEC 60947-4-1
[Ue] Rated Operational Voltage:
690 V AC 50/60 Hz IEC 60947-2
Maximum Operating Rate:
25 cyc/h
Electrical Durability:
20000 cycles AC-3 440 V In/2 || 10000 cycles AC-3 440 V In
Weee:
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Ik Degree Of Protection:
IK07 IEC 62262
Sustainable Offer Status:
Green Premium product
Mechanical Robustness:
vibrations +/- 1 mm 2...13.2 Hz IEC 60068-2-6 || vibrations 0.7 gn 13.2...100 Hz IEC 60068-2-6 || shocks 15 gn 11 ms IEC 60068-2-27
Standards:
CSA C22.2 No 60947-4-1 || UL 60947-4-1 || EN/IEC 60947-4-1 || EN/IEC 60947-2
Product Or Component Type:
motor circuit breaker
Line Rated Current:
50 A
Operating Altitude:
5000 m
$845.00

Description

TeSys GV motor circuit breaker, 3 poles (3P), 50A/690V, for protection of 3-phase motors 11-22kW@400V. It provides thermal magnetic protection and additional motor protection functions, breaking capacity Icu 100kA@400V, start-stop control by toggle, connection by Everlink BTR screw terminals. Thermal protection adjustable by dials with a setting current Ir in range 20-50A and a selectable tripping class 10 or 20, magnetic protection at 17 In. Additional protections have fixed pick-up and include short time delay protection Isd at 13 Ir, phase unbalance and loss protection, ground fault protection. It makes internal locations available for additional auxiliary contact blocks (OF, SD), and voltage trip units (MN, MX). Multi standards certified (IEC, UL, CSA, CCC, EAC, Marine, ATEX), Green Premium compliant (RoHS/REACh).
