Schneider Electric GV4PEM03N6 Motor circuit breaker, TeSys GV4, 3P, 3.5A, Icu 50kA, thermal magnetic multifunction, lugs terminals

Schneider Electric GV4PEM03N6 Motor circuit breaker, TeSys GV4, 3P, 3.5A, Icu 50kA, thermal magnetic multifunction, lugs terminals

Schneider Electric
SKU:
GV4PEM03N6
$895.00
(No reviews yet) Write a Review
Condition:
New
Current Stock:
Description
TeSys GV motor circuit breaker, 3 poles (3P), 3.5A/690V, for protection of 3-phase motors 0.55-1.5kW@400V. Multifunction circuit breaker, it provides thermal magnetic protection and advanced motor protection, breaking capacity Icu 50kA@400V, start-stop control by toggle, connection for bars or cables with lugs. Thermal protection adjustable by dials with a setting current Ir in range 1.4-3.5A and a selectable tripping class 10 or 20, magnetic protection at 17 In. Advanced protections are adjustable with a smartphone using wireless NFC and include short time delay protection Isd with a setting range 5-13 Ir, phase unbalance and loss protection, ground fault protection, locked rotor (jam), long start. It makes internal locations available for additional auxiliary contact blocks (OF, SD), and voltage trip units (MN, MX). It can be equiped externally with 1 or 2 auxiliary SDx modules in order to have alarming and fault differentiation. Multi standards certified (IEC, UL, CSA, CCC, EAC, Marine, ATEX), Green Premium compliant (RoHS/REACh).
Additional Information
Pvc Free:
Yes
Range Of Product:
TeSys GV4
Operating Altitude:
5000 m
Poles Description:
3P
Suitability For Isolation:
yes IEC 60947-1
Standards:
CSA C22.2 No 60947-4-1 || UL 60947-4-1 || EN/IEC 60947-4-1 || EN/IEC 60947-2
Fire Resistance:
960°C IEC 60695-2-11
Utilisation Category:
category A IEC 60947-2 || AC-3 IEC 60947-4-1
[Ue] Rated Operational Voltage:
690 V AC 50/60 Hz IEC 60947-2
Sustainable Offer Status:
Green Premium product
Electrical Durability:
40000 cycles AC-3 440 V In/2 || 40000 cycles AC-3 440 V In
Control Type:
toggle
Eu Rohs Directive:
Compliant with Exemptions
Country of Origin:
Poland
Ambient Air Temperature For Operation:
-25-70°C
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Device Short Name:
GV4PEM
Power Dissipation Per Pole:
4.6 W
Climatic Withstand:
IACS E10
Product Certifications:
IEC || UL || CSA || CCC || EAC || ATEX || EU-RO MR
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Circularity Profile:
ENVEOLI1704004EN
Color:
Gray RAL 7016)
[Uimp] Rated Impulse Withstand Voltage:
8 kV IEC 60947-2
Product Or Component Type:
motor circuit breaker
Net Weight:
1.45 kg
Maximum Operating Rate:
25 cyc/h
Mechanical Robustness:
vibrations +/- 1 mm 2...13.2 Hz IEC 60068-2-6 || vibrations 0.7 gn 13.2...100 Hz IEC 60068-2-6 || shocks 15 gn 11 ms IEC 60068-2-27
Depth:
116 mm
Pollution Degree:
3
Breaking Capacity:
100 kA Icu 220...240 V AC 50/60 Hz IEC 60947-2 || 50 kA Icu 380...415 V AC 50/60 Hz IEC 60947-2 || 50 kA Icu 440 V AC 50/60 Hz IEC 60947-2 || 15 kA Icu 525 V AC 50/60 Hz IEC 60947-2 || 65 kA 208Y/120 V AC 50/60 Hz UL 60947 || 65 kA 240 V AC 50/60 Hz
Operating Position:
any position
Product Name:
TeSys GV4 || TeSys Deca
Ip Degree Of Protection:
IP40 IEC 60529
Weee:
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Ambient Air Temperature For Storage:
-50-85°C
Rated Duty:
continuous IEC 60947-4-1
Magnetic Tripping Current:
59-59 A
Device Application:
motor protection
Environmental Disclosure:
ENVPEP1704004EN
[Ui] Rated Insulation Voltage:
800 V AC 50/60 Hz IEC 60947-2
Phase Failure Sensitivity:
yes IEC 60947-4-1
[Ith] Conventional Free Air Thermal Current:
115 A IEC 60947-4-1
Halogen Content Performance:
Halogen free plastic parts product
Line Rated Current:
3.5 A
Mechanical Durability:
40000 cycles
