Schneider Electric HGA260405 Circuit breaker, PowerPacT H, 40A, 2 pole, 600VAC, 18kA, I-Line, thermal magnetic, 80%, CA

Schneider Electric HGA260405 Circuit breaker, PowerPacT H, 40A, 2 pole, 600VAC, 18kA, I-Line, thermal magnetic, 80%, CA

Schneider Electric
SKU:
HGA260405
$2,007.00
(No reviews yet) Write a Review
Condition:
New
Current Stock:
Description
PowerPacT H-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT H-Frame circuit breakers are available with either thermal magnetic or Micrologic electronic trip protection units. This PowerPacT H-Frame circuit breaker provides thermal magnetic circuit protection with a breaking capacity of 18kA at 600VAC. All PowerPacT H-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT H circuit breakers are available in 2 and 3-pole unit mount and I-Line constructions. PowerPacT H I-Line circuit breakers are available in I-Line construction for easy installation and removal in I-Line applications. This breaker has I-Line terminations on the line side and mechanical lugs on the load side. This PowerPacT H, 40A, 2 pole, circuit breaker has a breaking capacity of 18kA at 600VAC. This circuit breaker has a continuous current rating of 80% with a CA phase connection. PowerPacT H circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
Additional Information
Line Rated Current:
40-40 A
Pollution Degree:
3 IEC 60947-1
Device Application:
distribution
California Proposition 65:
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
Network Frequency:
50/60 Hz
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Range:
PowerPact
Length:
16 mm
[Uimp] Rated Impulse Withstand Voltage:
8 kV IEC 60947-2
Operating Altitude:
< 6561.68 ft (2000 m) without derating || 5000 m with derating
Control Type:
toggle
Warranty:
18 months
Wire Stripping Length:
16 mm
Magnetic Tripping Current:
850-850 A
Continuous Current Rating:
0.8
Height:
3 in
[Ue] Rated Operational Voltage:
690 V AC 50/60 Hz IEC 60947-3
Awg Gauge:
AWG 14...AWG 3/0 aluminium/copper terminal
Color:
Black
Eu Rohs Directive:
Compliant
Breaking Capacity Code:
G
Mounting Mode:
I-Line bracket)
Quantity Per Set:
1
Ip Degree Of Protection:
front cover IP40 IEC 60529
Local Signaling:
switched off (OFF) 1 trip indicator green)
Quality Labels:
CE
Tightening Torque:
5-5 N.m 2.5-6 mm² (AWG 14...AWG 10) || 14-14 N.m 10-95 mm² (AWG 8...AWG 3/0)
Net Weight:
2.2 kg
Utilisation Category:
category A
Protected Poles Description:
2t
Breaking Capacity:
65 kA 240 V AC 50/60 Hz UL 489 || 35 kA 480 V AC 50/60 Hz UL 489 || 18 kA 600 V AC 50/60 Hz UL 489 || 20 kA 250 V DC UL 489 || 20 kA 500 V DC UL 489
Circularity Profile:
ENVEOLI1311006EN
Weight:
2.2 kg
Product Or Component Type:
circuit breaker
Mercury Free:
Yes
Depth:
86 mm
Rohs Exemption Information:
Yes
Suitability For Isolation:
yes IEC 60947-2
Trip Unit Technology:
thermal-magnetic
Communication Interface:
Modbus || Ethernet
Mounting Support:
bracket
Country of Origin:
United States
Magnetic Hold Current:
400 A
Number Of Slots:
2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
Electrical Connection:
I-Line connection, line || lugs, load
[Ui] Rated Insulation Voltage:
750 V IEC 60947-2
Sustainable Offer Status:
Green Premium product
Phase Connection:
CA
