Schneider Electric HLL26020 Circuit breaker, PowerPacT H, 20A, 2 pole, 600VAC, 50kA, lugs, thermal magnetic, 80%

Schneider Electric HLL26020 Circuit breaker, PowerPacT H, 20A, 2 pole, 600VAC, 50kA, lugs, thermal magnetic, 80%

Schneider Electric
SKU:
HLL26020
$2,364.00
(No reviews yet) Write a Review
Condition:
New
Current Stock:
Description
PowerPacT H-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT H-Frame circuit breakers are available with either thermal magnetic or Micrologic electronic trip protection units. This PowerPacT H-Frame circuit breaker provides thermal magnetic circuit protection with a breaking capacity of 50kA at 600VAC. All PowerPacT H-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT H circuit breakers are available in 2 and 3-pole unit mount and I-Line constructions. This breaker has lugs on both the line and load sides. This PowerPacT H, 20A, 2 pole, circuit breaker has a breaking capacity of 50kA at 600VAC. This circuit breaker has a continuous current rating of 80%. PowerPacT H circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
Additional Information
Width:
104 mm
Control Type:
toggle
Environmental Disclosure:
ENVPEP2206027EN
Trip Unit Technology:
thermal-magnetic
Product Certifications:
UL || CSA || NOM
Mounting Mode:
unit mount lug)
Awg Gauge:
AWG 14...AWG 3/0 aluminium/copper terminal
Product Name:
PowerPact H
Terminal Identifier:
AL150HD
Quantity Per Set:
1
Line Rated Current:
20-20 A
Breaking Capacity Code:
L
Product Or Component Type:
circuit breaker
Device Application:
distribution
Breaking Capacity:
125 kA 240 V AC 50/60 Hz UL 489 || 100 kA 480 V AC 50/60 Hz UL 489 || 50 kA 600 V AC 50/60 Hz UL 489 || 20 kA 250 V DC UL 489 || 50 kA 500 V DC UL 489
Ambient Air Temperature For Operation:
-25-70°C
Local Signaling:
switched off (OFF) 1 trip indicator green)
[Uimp] Rated Impulse Withstand Voltage:
8 kV IEC 60947-2
California Proposition 65:
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
Length:
16 mm
Net Weight:
2.2 kg
Wire Stripping Length:
16 mm
Utilisation Category:
category A
Country of Origin:
United States
Standards:
UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
Pollution Degree:
3 IEC 60947-1
Protected Poles Description:
2t
Circularity Profile:
ENVEOLI2206027EN
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Communication Interface:
Modbus || Ethernet
Mounting Support:
lug
Range:
PowerPact
Tightening Torque:
5-5 N.m 2.5-6 mm² (AWG 14...AWG 10) || 14-14 N.m 10-95 mm² (AWG 8...AWG 3/0)
Suitability For Isolation:
yes IEC 60947-2
Ambient Air Temperature For Storage:
-50-85°C
Ip Degree Of Protection:
front cover IP40 IEC 60529
Poles Description:
2P
[Ue] Rated Operational Voltage:
690 V AC 50/60 Hz IEC 60947-3
Eu Rohs Directive:
Compliant with Exemptions
Depth:
86 mm
Rohs Exemption Information:
Yes
Pvc Free:
Yes
Warranty:
18 months
Circuit Breaker Application:
HACR rated
Electrical Connection:
lugs, line || lugs, load
Color:
Black
Continuous Current Rating:
0.8
Quality Labels:
CE
