Schneider Electric HOM2175SB Surge protection device, Surgebreaker, 25kA, 120/240VAC, 1 phase, 3 wire, SPD type 1

Schneider Electric HOM2175SB Surge protection device, Surgebreaker, 25kA, 120/240VAC, 1 phase, 3 wire, SPD type 1

Schneider Electric
SKU:
HOM2175SB
$159.00
(No reviews yet) Write a Review
Condition:
New
Current Stock:
Description
The Homeline load center offer features Homeline circuit breakers, ground fault circuit breakers and arc fault interrupters. Homeline load centers enable the use of a full complement of accessories. Systems are single phase and are rated for indoor use or are rain proof. Homeline load centers are designed for residential and industrial use to protect electrical systems, equipment and people. This Surgebreaker is a secondary surge arrestor for Homeline load centers. It is designed to protect electrical service and major household appliances, excluding electronic devices. Designed for 3 wire 120/240 VAC single phase systems. Surgebreaker has a NEMA 1 indoor rating. This secondary surge protector is rated at 5 kA and has a SCCR of 22.5 kA. It has a plug on design and requires two pole positions. The LED indicator indicates operational status. The HOM Surgebreaker is UL Listed.
Additional Information
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Local Signaling:
1 LED green normal operation
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
[Ue] Rated Operational Voltage:
120/240 V AC
[Uc] Maximum Continuous Operating Voltage:
150 V || 300 V
Surge Current:
25 kA
Product Destination:
load center Homeline
Nema Degree Of Protection:
NEMA 1
California Proposition 65:
WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Eu Rohs Directive:
Compliant with Exemptions
Short-Circuit Protection:
25 kA
Line Rated Current:
10 kA
Product Or Component Type:
surge protection device
Standards:
UL 1449:ed. 4: type II
Warranty:
3 Years
Ambient Air Temperature For Operation:
65-65°C
Phase:
1 phase
Sustainable Offer Status:
Green Premium product
Wiring Configuration:
3-wire
Country of Origin:
Mexico
Environmental Disclosure:
ENVPEP2002007EN
Mercury Free:
Yes
Range Of Product:
Homeline
Rohs Exemption Information:
Yes
Circularity Profile:
ENVEOLI2002007EN
Depth:
2.6 in
