Schneider Electric LA9G4613 Straight terminal extension,TeSys Giga contactor,for LC1G400-500,4 pole,large connection,50 mm width

Schneider Electric LA9G4613 Straight terminal extension,TeSys Giga contactor,for LC1G400-500,4 pole,large connection,50 mm width

Schneider Electric
SKU:
LA9G4613
$75.00
(No reviews yet) Write a Review
Condition:
New
Current Stock:
Description
These accessories are straight terminal extension for TeSys Giga 400-500 contactor, 50mm wide connection. It is used to 4 Poles electrical circuit. They are screwed to the contactor terminals to increase the pitch for 50mm wide poles. The rated current is up to 500 A. It can cover -25°C to 60°C operation ambient air temperature, No derating up to 3000m altitude. Green Premium compliant (RoHs/Reach).
Additional Information
Pvc Free:
Yes
Halogen Content Performance:
Halogen free plastic parts product
Poles Description:
4P
Ambient Air Temperature For Storage:
-60-80°C
Product Certifications:
cULus
Net Weight:
1.07 kg
California Proposition 65:
WARNING: This product can expose you to chemicals including: Styrene, which is known to the State of California to cause cancer, and Bisphenol A (BPA), which is known to the State of California to cause birth defects or other reproductive harm. For m
Rohs Exemption Information:
Yes
Range Compatibility:
TeSys LC1G || TeSys LR9G
Ambient Air Temperature For Operation:
-40-60°C
Connection Pitch:
50 mm
Environmental Disclosure:
ENVPEP2105013
Operating Altitude:
9842.52 ft (3000 m) without derating || 5000 m with derating factor
Circularity Profile:
ENVEOLI2105013
Weight:
1.07 kg
Pollution Degree:
3 IEC 60947-1
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Product Or Component Type:
terminal extension
Quantity Per Set:
set of 4
Standards:
EN/IEC 60947-1 || UL 60947-1 || CSA C22.2 No 60947-1 || GB/T 14048
Device Short Name:
LA9G
Mercury Free:
Yes
Country of Origin:
China
Product Compatibility:
LC1G400...500
Accessory / Separate Part Category:
connection accessories
Depth:
30 mm
Ip Degree Of Protection:
IP20IEC 60529
Sustainable Offer Status:
Green Premium product
China Rohs Regulation:
X
Eu Rohs Directive:
Compliant with Exemptions
