Schneider Electric LC1DT25G7 IEC contactor, TeSys Deca, nonreversing, 25A resistive, 4 pole, 4 NO, 120VAC 50/60Hz coil, open style

(No reviews yet) Write a Review

Write a Review

Schneider Electric

Schneider Electric LC1DT25G7 IEC contactor, TeSys Deca, nonreversing, 25A resistive, 4 pole, 4 NO, 120VAC 50/60Hz coil, open style

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

LC1DT25G7

UPC:

MPN:

LC1DT25G7

Condition:

New

Device Short Name:

LC1D

Insulation Resistance:

> 10 MOhm for Signaling circuit

Height:

85 mm

[Ie] Rated Operational Current:

25 A (at <60°C) at <= 440 V AC AC-1 for power circuit

Flame Retardance:

V1 conforming to UL 94

Irms Rated Making Capacity:

140 A AC for Signaling circuit conforming to IEC 60947-5-1 || 250 A DC for Signaling circuit conforming to IEC 60947-5-1 || 250 A at 440 V for power circuit conforming to IEC 60947

Protective Cover:

with

[Uc] Control Circuit Voltage:

120 V AC 50/60 Hz

Associated Fuse Rating:

10 A gG for Signaling circuit conforming to IEC 60947-5-1 || 40 A gG at <= 690 V coordination type 1 for power circuit || 25 A gG at <= 690 V coordination type 2 for power circuit

Weight:

0.365 kg

Environmental Disclosure:

ENVPEP1501004

Protective Treatment:

THIEC 60068-2-30

Mercury Free:

Yes

Width:

45 mm

Range Of Product:

TeSys Deca

Mounting Support:

rail || plate

Overvoltage Category:

III

Tightening Torque:

control circuit 1.7 N.m screw clamp terminals flat Ø 6 mm || control circuit 1.7 N.m screw clamp terminals Philips No 2 || power circuit 1.7 N.m screw clamp terminals flat Ø 6 mm || power circuit 1.7 N.m screw clamp terminals Philips No 2 || contro

Pollution Degree:

3

Ip Degree Of Protection:

IP20 front face IEC 60529

Coil Technology:

without built-in suppressor module

Hold-In Power Consumption In Va:

7.5-7.5 VA 60 Hz cos phi 0.3 (at 20°C) || 7-7 VA 50 Hz cos phi 0.3 (at 20°C)

China Rohs Regulation:

Pro-active China RoHS declaration (out of China RoHS legal scope)

Fire Resistance:

850°C IEC 60695-2-1

Range:

TeSys || TeSys Deca

Reach Regulation:

Reference contains Substances of Very High Concern above the threshold

Country of Origin:

Indonesia

Product Certifications:

DNV || GL || CCC || LROS (Lloyds register of shipping) || RINA || BV || GOST || UL || CSA || CB

Circularity Profile:

ENVEOLI1501004

Signaling Circuit Frequency:

25...400 Hz

Pvc Free:

Yes

[Ui] Rated Insulation Voltage:

power circuit 600 V CSA || power circuit 600 V UL || Signaling circuit 690 V IEC 60947-1 || Signaling circuit 600 V CSA || Signaling circuit 600 V UL || power circuit 690 V IEC 60947-4-1

Product Or Component Type:

contactor

Utilisation Category:

AC-1 || AC-3 || AC-3e || AC-4

Rohs Exemption Information:

Yes

Inrush Power In Va:

70-70 VA 60 Hz cos phi 0.75 (at 20°C) || 70-70 VA 50 Hz cos phi 0.75 (at 20°C)

Minimum Switching Current:

5 mA for Signaling circuit

Climatic Withstand:

IACS E10 exposure to damp heat || IEC 60947-1 Annex Q category D exposure to damp heat

Rated Breaking Capacity:

250 A at 440 V for power circuit conforming to IEC 60947

[Ue] Rated Operational Voltage:

power circuit <= 690 V AC 25...400 Hz || power circuit <= 300 V DC

Average Impedance:

2.5 mOhm - Ith 25 A 50 Hz for power circuit

Toxic Heavy Metal Free:

Yes

Permissible Ambient Air Temperature Around The Device:

-40-60°C || 60-70°C with derating

[Ith] Conventional Free Air Thermal Current:

10 A (at 60°C) for Signaling circuit || 25 A (at 60°C) for power circuit

Electrical Durability:

0.8 Mcycles 25 A AC-1 <= 440 V

Safety Reliability Level:

B10d = 1369863 cycles contactor with nominal load EN/ISO 13849-1 || B10d = 20000000 cycles contactor with mechanical load EN/ISO 13849-1

Sustainable Offer Status:

Green Premium product

Operating Altitude:

0...9842.52 ft (0...3000 m)

Depth:

92 mm
