Schneider Electric LC1G1854KUEN Contactor, high power, TeSys Giga, standard version, 4 pole/NO, AC-1 <=440V 305A, 100-250VAC/DC coil

(No reviews yet) Write a Review

Write a Review

Schneider Electric

Schneider Electric LC1G1854KUEN Contactor, high power, TeSys Giga, standard version, 4 pole/NO, AC-1 <=440V 305A, 100-250VAC/DC coil

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

LC1G1854KUEN

UPC:

MPN:

LC1G1854KUEN

Condition:

New

Product Certifications:

CB Scheme || CCC || cULus || EAC || CE || UKCA || EU-RO-MR by DNV-GL

Rohs Exemption Information:

Yes

Mechanical Durability:

8 Mcycles

Protective Treatment:

TH

[Ie] Rated Operational Current:

185 A (at <60°C) at <= 440 V AC-3 || 305 A (at <40°C) at <= 1000 V AC-1

Operating Time:

40...70 ms closing || 15...50 ms opening

[Icw] Rated Short-Time Withstand Current:

1.5 kA - 10 s || 0.92 kA - 30 s || 0.74 kA - 1 min || 0.5 kA - 3 min || 0.4 kA - 10 min

Halogen Content Performance:

Halogen free plastic parts product

Permissible Ambient Air Temperature Around The Device:

-40-70°C at Uc

Associated Fuse Rating:

200 A aM at <= 440 V for motor || 160 A aM at <= 690 V for motor || 315 A gG at <= 690 V

Net Weight:

4.4 kg

Average Impedance:

0.00017 Ohm

Inrush Power In Va:

540-540 VA

Coil Technology:

built-in bidirectional peak limiting

Contactor Application:

power switching

Depth:

193 mm

Ambient Air Temperature For Operation:

-25-60°C

Connection Pitch:

35 mm

Inrush Power In W:

380 W

Reach Regulation:

Reference contains Substances of Very High Concern above the threshold

Mounting Support:

plate

Pvc Free:

Yes

Ambient Air Temperature For Storage:

-60-80°C

Utilisation Category:

AC-3 || AC-3e || AC-1 || AC-5a || AC-5b || AC-6a || AC-6b || DC-1 || DC-3 || DC-5

[Ui] Rated Insulation Voltage:

1000 V

[Ue] Rated Operational Voltage:

<= 1000 V AC 50/60 Hz || <= 460 V DC

Environmental Disclosure:

ENVPEP2105013

Country of Origin:

China

Mechanical Robustness:

vibrations 5-300 Hz 2 gn contactor open || vibrations 5-300 Hz 4 gn contactor closed || shocks 10 gn 11 ms contactor open || shocks 15 gn 11 ms contactor closed

Ip Degree Of Protection:

IP2X front face with shrouds IEC 60529 || IP2X front face with shrouds VDE 0106

Range:

TeSys

Mercury Free:

Yes

[Ith] Conventional Free Air Thermal Current:

305 A (at 40°C)

Maximum Operating Rate:

600 cyc/h AC-3 || 600 cyc/h AC-3e || 300 cyc/h AC-1

Auxiliary Contact Composition:

1 NO + 1 NC

Circularity Profile:

ENVEOLI2105013

Compatibility Code:

LC1G

Device Short Name:

LC1G

Safety Reliability Level:

B10d = 400000 cycles contactor with nominal load EN/ISO 13849-1 || B10d = 3000000 cycles contactor with mechanical load EN/ISO 13849-1

California Proposition 65:

WARNING: This product can expose you to chemicals including: Styrene, which is known to the State of California to cause cancer, and Bisphenol A (BPA), which is known to the State of California to cause birth defects or other reproductive harm. For m

Control Circuit Voltage Limits:

operational: 0.8 Uc Min...1.1 Uc Max (at <60°C) || drop-out: 0.1 Uc Max...0.45 Uc Min (at <60°C)

Eu Rohs Directive:

Compliant with Exemptions

[Uimp] Rated Impulse Withstand Voltage:

8 kV

Pole Contact Composition:

4 NO

Standards:

EN/IEC 60947-4-1 || EN/IEC 60947-5-1 || UL 60947-4-1 || CSA C22.2 No 60947-4-1 || JIS C8201-4-1 || JIS C8201-5-1 || UL 60335-1 || UL 60335-2-40:Annex JJ

Connections - Terminals:

power circuit: bar 2 - busbar cross section: 25 x 6 mm || power circuit: lugs-ring terminals 1 185-185 mm² || control circuit: push-in 1 0.2-2.5 mm² - cable stiffness: solid stranded without cable end || control circuit: push-in 1 0.25-2.5 mm² - c
