Schneider Electric LC1G5004BEEA Contactor, high power, TeSys Giga, advanced version, AC-1, <= 440V, 700A, 4 pole/NO, 24-48VAC/DC coil

(No reviews yet) Write a Review

Write a Review

Schneider Electric

Schneider Electric LC1G5004BEEA Contactor, high power, TeSys Giga, advanced version, AC-1, <= 440V, 700A, 4 pole/NO, 24-48VAC/DC coil

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

LC1G5004BEEA

UPC:

MPN:

LC1G5004BEEA

Condition:

New

Auxiliary Contact Composition:

1 NO + 1 NC

Hold-In Power Consumption In W:

6.0-6.0 W

Rated Breaking Capacity:

4600 A at 440 V

[Uc] Control Circuit Voltage:

24...48 V AC 50/60 Hz || 24...48 V DC

California Proposition 65:

WARNING: This product can expose you to chemicals including: Styrene, which is known to the State of California to cause cancer, and Bisphenol A (BPA), which is known to the State of California to cause birth defects or other reproductive harm. For m

Halogen Content Performance:

Halogen free plastic parts product

Mechanical Durability:

8 Mcycles

Compatibility Code:

LC1G

Weight:

8.7 kg

Rohs Exemption Information:

Yes

Eu Rohs Directive:

Compliant with Exemptions

Pvc Free:

Yes

Irms Rated Making Capacity:

1560 A at 440 V

Range:

TeSys

[Ith] Conventional Free Air Thermal Current:

250 A (at 40°C)

Inrush Power In Va:

490-490 VA

Control Circuit Voltage Limits:

operational: 0.8 Uc Min...1.1 Uc Max (at <60°C) || drop-out: 0.1 Uc Max...0.45 Uc Min (at <60°C)

Permissible Ambient Air Temperature Around The Device:

-40-70°C at Uc

Operating Time:

40...70 ms closing || 15...50 ms opening

Environmental Disclosure:

ENVPEP2105013

China Rohs Regulation:

X

Utilisation Category:

AC-3 || AC-3e || AC-1 || AC-5a || AC-5b || AC-6a || AC-6b || DC-1 || DC-3 || DC-5

Maximum Operating Rate:

600 cyc/h AC-3 || 600 cyc/h AC-3e || 300 cyc/h AC-1

Overvoltage Category:

III

[Ue] Rated Operational Voltage:

<= 1000 V AC 50/60 Hz || <= 460 V DC

Power Dissipation Per Pole:

40 W AC-1 - Ith 700 A || 20 W AC-3 - Ith 500 A

Protective Treatment:

TH

Color:

dark grey

[Ie] Rated Operational Current:

500 A (at <60°C) at <= 440 V AC-3 || 700 A (at <40°C) at <= 1000 V AC-1

Coil Technology:

built-in bidirectional peak limiting

Hold-In Power Consumption In Va:

17.9-17.9 VA

Net Weight:

8.7 kg

[Uimp] Rated Impulse Withstand Voltage:

8 kV

Range Of Product:

TeSys Giga

Mechanical Robustness:

vibrations 5-300 Hz 2 gn contactor open || vibrations 5-300 Hz 4 gn contactor closed || shocks 10 gn 11 ms contactor open || shocks 15 gn 11 ms contactor closed

Pole Contact Composition:

4 NO

Inrush Power In W:

350 W

Ambient Air Temperature For Operation:

-25-60°C

Mounting Support:

plate

Connection Pitch:

45 mm

Country of Origin:

China

Depth:

226 mm

[Icw] Rated Short-Time Withstand Current:

4.0 kA - 10 s || 2.8 kA - 30 s || 2.2 kA - 1 min || 1.5 kA - 3 min || 1.2 kA - 10 min

Mercury Free:

Yes

Average Impedance:

0.00008 Ohm

Device Short Name:

LC1G
