Schneider Electric LC1K09107F7 Contactor, TeSys K, 3P, AC-3, lt or eq to 440V 9A, 1 NO aux., 110VAC coil

(No reviews yet) Write a Review

Write a Review

Schneider Electric

Schneider Electric LC1K09107F7 Contactor, TeSys K, 3P, AC-3, lt or eq to 440V 9A, 1 NO aux., 110VAC coil

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

LC1K09107F7

UPC:

MPN:

LC1K09107F7

Condition:

New

Product Certifications:

CB Scheme || CCC || UL || CSA || EAC || CE || UKCA

Toxic Heavy Metal Free:

Yes

[Ie] Rated Operational Current:

9 A (at <60°C) at <= 440 V AC AC-3 for power circuit || 9 A (at <60°C) at <= 440 V AC AC-3e for power circuit || 20 A (at <60°C) at <= 690 V AC AC-1 for power circuit

Depth:

57 mm

Protective Treatment:

TC IEC 60068 || TC DIN 50016

Device Short Name:

LC1K

Signaling Circuit Frequency:

<= 400 Hz

[Ue] Rated Operational Voltage:

power circuit <= 690 V AC <= 400 Hz || Signaling circuit <= 690 V AC <= 400 Hz

Device Application:

control

Safety Reliability Level:

B10d = 1369863 cycles contactor with nominal load EN/ISO 13849-1 || B10d = 20000000 cycles contactor with mechanical load EN/ISO 13849-1

Rohs Exemption Information:

Yes

Auxiliary Contact Composition:

1 NO

Environmental Disclosure:

ENVPEP1503003EN

Poles Description:

3P

Connections - Terminals:

Faston terminals 2 2.8 mm) || Faston terminals 1 6.35 mm)

Product Or Component Type:

contactor

Average Impedance:

3 mOhm - Ith 20 A 50 Hz for power circuit

Utilisation Category:

AC-3 || AC-3e || AC-1 || AC-4

Operating Altitude:

6561.68 ft (2000 m) without derating

Height:

58 mm

Control Circuit Type:

AC 50/60 Hz

Flame Retardance:

V1 conforming to UL 94 || requirement 2 conforming to NF F 16-101 || requirement 2 conforming to NF F 16-102

Pole Contact Composition:

3 NO

Sustainable Offer Status:

Green Premium product

Heat Dissipation:

1.3-1.3 W

Minimum Switching Voltage:

17 V for Signaling circuit

Sustainable Packaging:

Yes

Minimum Switching Current:

5 mA for Signaling circuit

Maximum Operating Rate:

3600 cyc/h

Reach Regulation:

Free of Substances of Very High Concern above the threshold

Standards:

EN/IEC 60947-4-1 || GB/T 14048.4 || UL 60947-4-1 || CSA C22.2 No 60947-4-1 || JIS C8201-4-1 || IEC 60335-1:Clause 30.2 || IEC 60335-2-40:Annex JJ || UL 60335-2-40:Annex JJ

Mercury Free:

Yes

Hold-In Power Consumption In Va:

4.5-4.5 VA (at 20°C)

Control Circuit Voltage Limits:

operational: 0.8...1.15 Uc (at <50°C) || drop-out: >= 0.20 Uc (at <50°C)

[Uc] Control Circuit Voltage:

110 V AC 50/60 Hz

Irms Rated Making Capacity:

110 A AC for power circuit conforming to IEC 60947 || 110 A AC for Signaling circuit conforming to IEC 60947

Eu Rohs Directive:

Compliant

Mechanical Robustness:

shocks contactor closed, on X axis10 Gn for 11 ms IEC 60068-2-27 || shocks contactor closed, on Y axis15 Gn for 11 ms IEC 60068-2-27 || shocks contactor closed, on Z axis15 Gn for 11 ms IEC 60068-2-27 || shocks contactor opened, on X axis6 Gn for 11

Weee:

The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.

Mechanical Durability:

10 Mcycles

Operating Time:

10...20 ms coil de-energisation and NO opening || 10...20 ms coil energisation and NO closing

Reach Free Of Svhc:

Yes

China Rohs Regulation:

Pro-active China RoHS declaration (out of China RoHS legal scope)

Range:

TeSys

Inrush Power In Va:

30-30 VA (at 20°C)

[Icw] Rated Short-Time Withstand Current:

90 A 50°C - 1 s for power circuit || 85 A 50°C - 5 s for power circuit || 80 A 50°C - 10 s for power circuit || 60 A 50°C - 30 s for power circuit || 45 A 50°C - 1 min for power circuit || 40 A 50°C - 3 min for power circuit || 20 A 50°C - >= 15 min

Circularity Profile:

ENVEOLI1503003EN

Overvoltage Category:

III
