Schneider Electric LX1G3RKUEN Control module,TeSys Giga,100-250V AC/DC,for LC1G265-330/3P standard version

Schneider Electric LX1G3RKUEN Control module,TeSys Giga,100-250V AC/DC,for LC1G265-330/3P standard version

Schneider Electric
SKU:
LX1G3RKUEN
$235.00
(No reviews yet) Write a Review
Condition:
New
Current Stock:
Description
It is a 100-250V AC/DC control module for 3 poles TeSys Giga 265-300 contactor (advanced version). Coil designed for less energy consumption and wider voltage band-width, connection by spring terminal. It allows contactor operation with high AC-3 operating rates until 600 cycles/hour and environments until 60°C. Control module has connectors for connecting the coil control A1, A2 circuit, pole status and diagnostic signaling circuits. Local Contact Wear Diagnosis (CWD) as standard function, continuous monitoring with healthy and alarm indicators. It provides IP2x protection in Front face with shrouds conforming to IEC 60529 and VDE 0106. It is accessible from the front and maintained with very low down times. Unique QR code provides quick access to complete product data.
Additional Information
Rohs Exemption Information:
Yes
Halogen Content Performance:
Halogen free plastic parts product
Inrush Power In Va:
840-840 VA 240 V AC, 60 Hz
Ambient Air Temperature For Operation:
-25-60°C
Coil Technology:
built-in bidirectional peak limiting
China Rohs Regulation:
X
Range Compatibility:
TeSys G LX1G contactor coil
Eu Rohs Directive:
Compliant with Exemptions
Maximum Operating Rate:
600 cyc/mn 60°C
Poles Description:
3P
Inrush Power In W:
645.0 W DC
Ambient Air Temperature For Storage:
-60-80°C
Permissible Ambient Air Temperature Around The Device:
-40-70°C at Uc
Hold-In Power Consumption In W:
5.9-5.9 W DC
[Uc] Control Circuit Voltage:
100...250 V AC/DC 50/60 Hz
Ip Degree Of Protection:
IP20 IEC 60529
Depth:
93.0 mm
Country of Origin:
China
Control Circuit Voltage Limits:
operational 0.8...1.1 Uc 60°C) || drop-out 0...0.45 Uc 60°C)
Connections - Terminals:
control circuit push-in termination 1 0.2-2.5 mm² solid stranded without cable end sleeve AWG 26...AWG 12 || control circuit push-in termination 1 0.25-2.5 mm² flexible with cable end sleeve AWG 24...AWG 14 || control circuit push-in termination 2
California Proposition 65:
WARNING: This product can expose you to chemicals including: Styrene, which is known to the State of California to cause cancer, and Bisphenol A (BPA), which is known to the State of California to cause birth defects or other reproductive harm. For m
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Mechanical Durability:
5 Mcycles
Sustainable Offer Status:
Green Premium product
Electromagnetic Compatibility:
EMC immunity conforming to IEC 60947-4-1 || emission tests criteria A conforming to IEC 60947-4-1 || immunity to radiated radio-electrical interference - test level: 20 V/m conforming to EN/IEC 61000-4-3 || voltage dips and interruptions immunity tes
Circularity Profile:
ENVEOLI2105013
Product Or Component Type:
contactor coil
Operating Time:
20...35 ms opening || 40...55 ms closing
Pvc Free:
Yes
Hold-In Power Consumption In Va:
10.6-10.6 VA 240 V AC, 60 Hz
Range:
TeSys
Product Compatibility:
LC1G265...330
Environmental Disclosure:
ENVPEP2105013
Quantity Per Set:
1
Device Short Name:
LX1G
Pollution Degree:
3 IEC 60947-1
Standards:
EN/IEC 60947-4-1 || UL 60947-4-1A || CSA C22.2 No 60947-4-1
Operating Altitude:
9842.52 ft (3000 m) without derating || 5000 m with derating factor
Mercury Free:
Yes
