Schneider Electric

Schneider Electric MJP36600 Circuit breaker, PowerPacT M, 600A, 3 pole, 600VAC, 25kA, lugs, ET 1.0, 80%

(No reviews yet) Write a Review
SKU:
MJP36600
MPN:
MJP36600
Condition:
New
Mercury Free:
Yes
Pvc Free:
Yes
Terminal Identifier:
AL800M23K
Weight:
29 lb(US)
Sustainable Offer Status:
Green Premium product
Poles Description:
3P
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Product Certifications:
UL || CSA || NOM
Mounting Support:
lug
Rohs Exemption Information:
Yes
Network Frequency:
50/60 Hz
Quantity Per Set:
1
[Uimp] Rated Impulse Withstand Voltage:
8 kV IEC 60947-2
Product Name:
PowerPact M
[Ics] Rated Service Breaking Capacity:
35 kA 240 V AC 50/60 Hz IEC 60947-2 || 25 kA 380/415 V AC 50/60 Hz IEC 60947-2
Standards:
UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
Continuous Current Rating:
0.8
Country of Origin:
United States
Utilisation Category:
category A
Device Application:
distribution
Warranty:
18 months
Tightening Torque:
50-50 N.m 95-240 mm² (3 x AWG 3/0...3 x 500 kcmil)
Control Type:
operating handle
Quality Labels:
CE
Wire Stripping Length:
25 mm
Awg Gauge:
3 x AWG 3/0...3 x 500 kcmil aluminium/copper
Ambient Air Temperature For Storage:
-50-85°C
California Proposition 65:
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
Breaking Capacity:
AIR 100 kA 240 V AC 50/60 Hz UL 489 || AIR 65 kA 480 V AC 50/60 Hz UL 489 || AIR 25 kA 600 V AC 50/60 Hz UL 489 || Icu 65 kA 240 V AC 50/60 Hz IEC 60947-2 || Icu 50 kA 380/415 V AC 50/60 Hz IEC 60947-2
Range:
PowerPact
[Ui] Rated Insulation Voltage:
750 V IEC 60947-2
Trip Unit Technology:
electronic, basic, ET 1.0,
Suitability For Isolation:
yes IEC 60947-2
Pollution Degree:
3 IEC 60947-1
Line Rated Current:
600-600 A
Local Signaling:
1 trip indicator green)
Circuit Breaker Application:
HACR rated
Trip Unit Name:
ET 1.0
Mounting Mode:
unit mount lug)
Depth:
8.05 in
Breaking Capacity Code:
J
Environmental Disclosure:
ENVPEP2206030EN
Net Weight:
29 lb(US)
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Number Of Slots:
2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 voltage release MN or MX plug-in)
Eu Rohs Directive:
Compliant with Exemptions
$9,456.00

Description

PowerPacT M-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT M-Frame circuit breakers have either a fixed long time electronic trip unit or an adjustable amperage version. This circuit breaker has an electronic trip unit, ET 1.0. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT M circuit breakers are available in 2 and 3-pole unit mount or I-Line construction. This unit has terminal nuts on the line side and lugs on the load side. This PowerPacT M, 600A, 3 pole, circuit breaker has an interrupting rating of 25kA at 600VAC. This circuit breaker has a continuous current rating of 80%. PowerPacT M circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
