Schneider Electric NSYS3D101230D S3D H1000Xw1200Xd300 2 Pl.Doors

(No reviews yet) Write a Review
SKU:
NSYS3D101230D
UPC:
3606480160288
Condition:
New
Standards:
IEC 62208
Product Or Component Type:
compact enclosure
Accessibility For Operation:
front
Number Of Doors:
front face 2
Device Application:
multi-purpose
Rohs Exemption Information:
Yes
Ik Degree Of Protection:
IK10 IEC 62262
Mercury Free:
Yes
Lock Type:
3 points lock, 3 mm double-bar
Color:
Gray RAL 7035)
Type Of Gland Plate:
standard
Material:
steel
Warranty:
18 months
Product Certifications:
LR || cUL || DNV || BV || GL || UL
Electromagnetic Compatibility:
electromagnetic field immunity test
Device Composition:
1 body || 2 cable gland plate || 1 lock || 2 door
Net Weight:
53 kg
Eu Rohs Directive:
Pro-active compliance (Product out of EU RoHS legal scope)
Product Name:
Spacial S3D
Mounting Plate Description:
without mounting plate
Ip Degree Of Protection:
IP55 IEC 60529
Enclosure Nominal Depth:
300 mm
Removable Parts:
door by hinges || cable gland plate by screws
Sustainable Offer Status:
Green Premium product
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Enclosure Nominal Width:
1200 mm
Enclosure Nominal Height:
1000 mm
Range:
Spacial
Surface Finish:
epoxy-polyester powder
Door Opening Side:
reversible 120 °)
Door Type:
Solid
Environmental Disclosure:
ENVPEP100104EN
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Installation Accessory Type:
wall-mounting
Variant Particularity:
single piece body || gutter-shaped front rail double sheet thickness
Circularity Profile:
N/A
Brochure:
View
Datasheet:
View
$524.54

Description

Spacial S3D wall mounted steel enclosure with 2 plain doors. 1000 x 1200 x 300 mm. Single piece body, without mounting plate. Robust construction based on a new design. 3-point closure system with handle and 3 mm double bar lock insert. Steel made, epoxy-polyester powder finish. Gutter shaped front rail double sheet thickness. Protection IP 55, IK10, Grey RAL 7035. 2 cable gland plates included, standard. Extensive range of accessories. Packaging is reusable after assembly.
