Schneider Electric NSYTRASF520M Fuse Carrier For 5X20 Mm Fuse, 6,2Mm Wid Pack of 10
Schneider Electric
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Component carrier, Linergy TR, for 5x20mm fuse, 6,2mm width, with 110-250V light indicator
- Thickness:
- 6.2 mm
- Provided Equipment:
- 110...250 V light indicator
- Product Compatibility:
- TRV screw terminal - removable carrier disconnect terminal block || TRR spring terminal - removable carrier disconnect terminal block || TRP push-in - removable carrier disconnect terminal block
- Halogen Content Performance:
- Halogen free plastic parts product
- Mercury Free:
- Yes
- Product Name:
- TR
- Product Or Component Type:
- component carrier
- Number Of Terminals:
- 2 || 3
- Reach Free Of Svhc:
- Yes
- Cable Cross Section:
- 4-4 mm² || 2.5-2.5 mm²
- Number Of Measurement Input:
- 0 || 1
- China Rohs Regulation:
- Pro-active China RoHS declaration (out of China RoHS legal scope)
- Quantity Per Set:
- set of 10
- Device Short Name:
- TRA
- Net Weight:
- 4.18 g
- Fuse Size:
- 5 x 20 mm
- Mounting Mode:
- plug-in
- Color:
- Black
- Accessory / Separate Part Category:
- connection accessory
- Terminal Block Level:
- 2 || 1
- Toxic Heavy Metal Free:
- Yes
- Length:
- 28 mm
- Reach Regulation:
- Free of Substances of Very High Concern above the threshold
- Range:
- Linergy
- Rohs Exemption Information:
- Yes
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Catalog:
- View
- Datasheet:
- View
