Schneider Electric NSYTRV44DPE Screw Terminal, Double Level, Protective

Schneider Electric NSYTRV44DPE Screw Terminal, Double Level, Protective Pack of 50

Schneider Electric
SKU:
NSYTRV44DPE
|
UPC:
3606480532054
Availability:
Factory stock
$1,187.50
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
Terminal block, Linergy TR, green-yellow, 4mm2, 2 level connt, protective earth, 4 points, Set of 50
Additional Information
Tightening Torque:
0.6-0.8 N.m
Resistivity:
10000 MΩ.m IEC 60093 || 10000 MΩ.m VDE 0303-T30
Product Compatibility:
Spacial enclosures
Terminal Block Type:
protective earth
Product Certifications:
LR || GL || CSA || ATEX || EAC || DNV || IEC-Ex || cURus
Range Compatibility:
Prisma G || Prisma P || Prisma PH || Prisma Pack || Spacial || Kaedra || Pragma || TeSys
Halogen Content Performance:
Halogen free plastic parts product
Number Of Measurement Input:
4
Ambient Air Temperature For Operation:
-40-130 °C IEC 60216-1 || -40-130 °C VDE 0304-T21
Warranty:
18 months
Weee:
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Dielectric Loss:
0.01 at 1 MHz IEC 60250 || 0.01 at 1 MHz VDE 0303-T4
Device Short Name:
TRV
Dielectric Strength:
1000 V IEC 60243-1
Environmental Disclosure:
ENVPEP2309022EN
Product Or Component Type:
terminal block
Mounting Mode:
clip-on
Connection Position:
sideways
Material:
polyamide 6/6: insulating case
Quantity Per Set:
set of 50
Cable Cross Section:
0.14-6 mm², solid || 0.2-4 mm², flexible with cable end || 0.14-6 mm², flexible without cable end
Nominal Cross Section:
4 mm²
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Height:
65 mm
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Terminal Block Level:
2
Range:
Linergy
California Proposition 65:
WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Connections - Terminals:
1 x screw terminal upstream || 1 x screw terminal downstream
Width:
6.2 mm
Surface Resistance:
1000 GΩ IEC 60093 || 1000 GΩ VDE 0303-T30
Circularity Profile:
N/A
Number Of Terminals:
2
Sustainable Offer Status:
Green Premium product
Rohs Exemption Information:
Yes
Eu Rohs Directive:
Compliant with Exemptions
Product Name:
Linergy TR
Creep Resistance:
500 CTI (> 400 kB) IEC 60093 || 500 CTI (> 400 kB) VDE 0303-T30
Wire Stripping Length:
9 mm
Tool Type:
connection screwdriver || disconnection screwdriver
Net Weight:
23.3 g
Flame Retardance:
V0 0.8 mm UL 94
Dielectric Constant:
3.7 at 1 MHz
Mercury Free:
Yes
Color:
green-yellow
Length:
69.9 mm
