Schneider Electric PJA36040U33A Circuit breaker, PowerPacT P, 400A, 3 pole, 600VAC, 25kA, I-Line, Micrologic 5.0, 80%, ABC

(No reviews yet) Write a Review
SKU:
PJA36040U33A
MPN:
PJA36040U33A
Condition:
New
Height:
9 in
Pollution Degree:
3 IEC 60947-1
Range:
PowerPact
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Sustainable Offer Status:
Green Premium product
Number Of Slots:
2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
Awg Gauge:
3 x AWG 3/0...500 kcmil aluminium/copper
[Ue] Rated Operational Voltage:
600 V AC 50/60 Hz UL 489
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Environmental Disclosure:
ENVPEP2206033EN
Country of Origin:
United States
Product Certifications:
UL || CSA || NOM
Breaking Capacity Code:
J
California Proposition 65:
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
Length:
25 mm
Standards:
UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
Height:
12.86 in
Wire Stripping Length:
25 mm
Control Type:
toggle
Product Or Component Type:
circuit breaker
Mounting Mode:
I-Line bracket)
Warranty:
18 months
Trip Unit Technology:
electronic, standard, MicroLogic 5.0, LSI
Ip Degree Of Protection:
front cover IP40
Poles Description:
3P
Breaking Capacity:
AIR 100 kA 240 V AC 50/60 Hz UL 489 || AIR 65 kA 480 V AC 50/60 Hz UL 489 || AIR 25 kA 600 V AC 50/60 Hz UL 489 || Icu 65 kA 240 V AC 50/60 Hz IEC 60947-2 || Icu 50 kA 380/415 V AC 50/60 Hz IEC 60947-2
Circuit Breaker Application:
HACR rated
Mercury Free:
Yes
[Uimp] Rated Impulse Withstand Voltage:
8 kV IEC 60947-2
Phase Connection:
ABC
Eu Rohs Directive:
Compliant with Exemptions
Pvc Free:
Yes
Terminal Identifier:
AL800M23K
Network Frequency:
50/60 Hz
Trip Unit Name:
MicroLogic 5.0
Mounting Support:
bracket
Operating Altitude:
< 6561.68 ft (2000 m) without derating || 13123.36 ft (4000 m) with derating
Tightening Torque:
50-50 N.m 95-240 mm² (3 x AWG 3/0...500 kcmil) || 1.0-1.3 N.m
Quality Labels:
CE
Line Rated Current:
400-400 A
Ambient Air Temperature For Storage:
-50-85°C
Continuous Current Rating:
0.8
Mounting Height:
9 in
Local Signaling:
1 trip indicator green)
Quantity Per Set:
1
Net Weight:
32 lb(US)
Circularity Profile:
ENVEOLI2206033EN
Long Time Pick-Up Adjustment Range:
0.4...1 x Ir
$16,608.00

Description

PowerPacT P-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT P-Frame circuit breakers have either a fixed long time electronic trip unit, ET 1.0I, or Micrologic trip units. Micrologic trip units can be interchanged in the field to allow for maximum flexibility; the basic electronic trip unit doesn't have that interchangeability. This circuit breaker has a Micrologic Interchangeable Standard with a 5.0 trip unit and an LSI function. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT P circuit breakers are available in 2, 3, and 4-pole unit mount, I-Line, or drawout construction. This unit has I-Line terminations on the line side and mechanical lugs on the load side. This PowerPacT P, 400A, 3 pole, circuit breaker has an interrupting rating of 25kA at 600VAC. This circuit breaker has a continuous current rating of 80% with an ABC phase connection. PowerPacT P circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
