Schneider Electric PJA36060CU33A Circuit breaker, PowerPacT P, 600A, 3 pole, 600VAC, 25kA, I-Line, Micrologic 5.0, 100%, ABC

(No reviews yet) Write a Review

Write a Review

Schneider Electric

Schneider Electric PJA36060CU33A Circuit breaker, PowerPacT P, 600A, 3 pole, 600VAC, 25kA, I-Line, Micrologic 5.0, 100%, ABC

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

PJA36060CU33A

UPC:

MPN:

PJA36060CU33A

Condition:

New

Length:

25 mm

Quality Labels:

CE

Ambient Air Temperature For Storage:

-50-85°C

Continuous Current Rating:

1

Ambient Air Temperature For Operation:

-25-70°C

Poles Description:

3P

Circularity Profile:

ENVEOLI2206033EN

[Ics] Rated Service Breaking Capacity:

35 kA 240 V AC 50/60 Hz IEC 60947-2 || 25 kA 380/415 V AC 50/60 Hz IEC 60947-2

Breaking Capacity Code:

J

Standards:

UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2

Awg Gauge:

3 x AWG 3/0...500 kcmil aluminium/copper

Mounting Support:

bracket

Quantity Per Set:

1

Warranty:

18 months

Local Signaling:

1 trip indicator green)

Net Weight:

32 lb(US)

Weight:

32 lb(US)

Product Or Component Type:

circuit breaker

Width:

8.27 in

Eu Rohs Directive:

Compliant with Exemptions

Line Rated Current:

600-600 A

Electrical Connection:

I-Line connection, line || lugs, load

Control Type:

toggle

Operating Altitude:

< 6561.68 ft (2000 m) without derating || 13123.36 ft (4000 m) with derating

Country of Origin:

United States

[Ui] Rated Insulation Voltage:

750 V IEC 60947-2

Tightening Torque:

50-50 N.m 95-240 mm² (3 x AWG 3/0...500 kcmil) || 1.0-1.3 N.m

Wire Stripping Length:

25 mm

[Uimp] Rated Impulse Withstand Voltage:

8 kV IEC 60947-2

Rohs Exemption Information:

Yes

Mercury Free:

Yes

Pvc Free:

Yes

Product Name:

PowerPact P

Range:

PowerPact

Number Of Slots:

2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)

Mounting Height:

9 in

Device Application:

distribution

Trip Unit Technology:

electronic, standard, MicroLogic 5.0, LSI

Height:

12.86 in

Circuit Breaker Application:

HACR rated

Pollution Degree:

3 IEC 60947-1

China Rohs Regulation:

Product out of China RoHS scope. Substance declaration for your information.

Sustainable Offer Status:

Green Premium product

Network Frequency:

50/60 Hz

Product Certifications:

UL || CSA || NOM

Breaking Capacity:

AIR 100 kA 240 V AC 50/60 Hz UL 489 || AIR 65 kA 480 V AC 50/60 Hz UL 489 || AIR 25 kA 600 V AC 50/60 Hz UL 489 || Icu 65 kA 240 V AC 50/60 Hz IEC 60947-2 || Icu 50 kA 380/415 V AC 50/60 Hz IEC 60947-2

Long Time Pick-Up Adjustment Range:

0.4...1 x Ir

Phase Connection:

ABC

Ip Degree Of Protection:

front cover IP40

Height:

9 in
