Schneider Electric QOU135VH Mini circuit breaker, QOU, 35A, 1 pole, 120/240 VAC, 22kA

Schneider Electric QOU135VH Mini circuit breaker, QOU, 35A, 1 pole, 120/240 VAC, 22kA

Schneider Electric
SKU:
QOU135VH
$101.00
(No reviews yet) Write a Review
Condition:
New
Current Stock:
Description
QOU unit mount miniature circuit breakers (cable-in/cable-out) are ideal for OEM applications. QOU breakers are one, two or three pole thermal magnetic circuit breakers which provide overcurrent protection and switching on ac and dc systems. These circuit breakers have an over center, trip-free toggle mechanism with quick-make, quick break action and positive handle indication. These QOU miniature circuit breakers can be DIN rail mounted, surface mounted or flush mounted using mounting feet. This one pole QOU miniature circuit breaker is rated as 35A, 120/240VAC. This unit provides 22 kA breaking capacity. A full line of accessories are available for these circuit breakers. The slotted box lugs will accept one 14 AWG to 2 AWG copper or aluminum wire. QOU circuit breakers are UL Listed and CSA Certified.
Additional Information
Awg Gauge:
AWG 14...AWG 2 aluminium/copper
Eu Rohs Directive:
Compliant with Exemptions
Range Of Product:
QOU
Halogen Content Performance:
Halogen free product
Toxic Heavy Metal Free:
Yes
Mounting Mode:
unit mount
Circuit Breaker Application:
HACR rated
Circuit Breaker Type:
standard
Country of Origin:
Mexico
Tightening Torque:
45-45 lbf.in (AWG 14...AWG 2)
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Product Or Component Type:
miniature circuit-breaker
Warranty:
18 months
Mercury Free:
Yes
Electrical Connection:
slotted box lugs, line side || slotted box lugs, load side
Product Certifications:
IEC || CSA || UL Listed
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Rohs Exemption Information:
Yes
Line Rated Current:
35 A
Depth:
2.95 in
[Ue] Rated Operational Voltage:
120/240 V AC
