Schneider Electric RGA36120CU43A Circuit breaker, PowerPacT R, 1200A, 3 pole, 600VAC, 18kA, I-Line, Micrologic 5.0A, 100%

Schneider Electric RGA36120CU43A Circuit breaker, PowerPacT R, 1200A, 3 pole, 600VAC, 18kA, I-Line, Micrologic 5.0A, 100%

Schneider Electric
SKU:
RGA36120CU43A
$5,890.00
(No reviews yet) Write a Review
Condition:
New
Current Stock:
Description
PowerPacT R-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT R-Frame circuit breakers have either a fixed long time electronic trip unit, ET 1.0I, or Micrologic trip units. Micrologic trip units can be interchanged in the field to allow for maximum flexibility; the basic electronic trip unit doesn't have that interchangeability. This circuit breaker has a Micrologic Interchangeable Ammeter with a 5.0A trip unit and an LSI function. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT R circuit breakers are available in 2, 3, and 4-pole unit mount and I-Line construction (I-Line construction is available for 1000A and 1200A rated circuit breakers only). This unit has I-Line terminations on the line side and mechanical lugs on the load side. This PowerPacT P, 1200A, 3 pole, circuit breaker has an interrupting rating of 18kA at 600VAC. This circuit breaker has a continuous current rating of 100% with an ABC phase connection. PowerPacT R circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
Additional Information
Device Application:
distribution
Pvc Free:
Yes
Width:
14.96 in
Warranty:
18 months
Circuit Breaker Application:
HACR rated
Product Or Component Type:
circuit breaker
Line Rated Current:
1200-1200 A
Suitability For Isolation:
yes IEC 60947-2
Mounting Support:
bracket
Country of Origin:
United States
Length:
30 mm
Terminal Identifier:
AL1200R53K
Mercury Free:
Yes
Quantity Per Set:
1
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Awg Gauge:
4 x AWG 3/0…600 kcmil aluminium/copper || 4 x AWG 3/0...500 kcmil copper
Weight:
52 lb(US)
Range:
PowerPact
[Ics] Rated Service Breaking Capacity:
25 kA 240 V AC 50/60 Hz IEC 60947-2 || 20 kA 380/415 V AC 50/60 Hz IEC 60947-2
Net Weight:
52 lb(US)
Product Certifications:
UL || CSA || NOM
[Uimp] Rated Impulse Withstand Voltage:
8 kV IEC 60947-2
Control Type:
operating handle
California Proposition 65:
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
Continuous Current Rating:
1
Number Of Slots:
2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 voltage release MN or MX plug-in)
Standards:
UL || CSA || NEMA || NMX J-266 || IEC 60947-2
Pollution Degree:
3 IEC 60947-1
Network Frequency:
50/60 Hz
Ambient Air Temperature For Storage:
-50-85°C
Rohs Exemption Information:
Yes
[Ue] Rated Operational Voltage:
600 V AC 50/60 Hz UL 489
Operating Altitude:
< 6561.68 ft (2000 m) without derating || 13123.36 ft (4000 m) with derating
Environmental Disclosure:
ENVPEP2206034EN
Electrical Connection:
I-Line connection, line || lugs, load
Mounting Mode:
I-Line bracket)
Breaking Capacity:
AIR 65 kA 240 V AC 50/60 Hz UL 489 || AIR 35 kA 480 V AC 50/60 Hz UL 489 || AIR 18 kA 600 V AC 50/60 Hz UL 489 || Icu 50 kA 240 V AC 50/60 Hz IEC 60947-2 || Icu 35 kA 380/415 V AC 50/60 Hz IEC 60947-2
Circularity Profile:
ENVEOLI2206034EN
Sustainable Offer Status:
Green Premium product
Quality Labels:
CE
[Ui] Rated Insulation Voltage:
750 V IEC 60947-2
Local Signaling:
alarm 1 LED yellow)long-time pick up) || 1 LED red)long-time pick up) || trip causes 1 LED red) || 1 LED red)digital ammeter) || phase-loading LED green)load balancing)
Tightening Torque:
28-28 N.m 95-240 mm² (4 x AWG 3/0…600 kcmil)
Poles Description:
3P
Eu Rohs Directive:
Compliant with Exemptions
Halogen Content Performance:
Halogen free plastic parts product
Breaking Capacity Code:
G
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
