Schneider Electric ZB4BA0 Pushbutton Operator Head
Schneider Electric
$11.00
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
This Harmony XB4, flush button head without cap operates with a spring return / impulse mechanism. This button head without cap allows users to customize it with any compatible desired cap to support your machines and operating functions. It is easily installed and replaced on compatible complete push button units and contact blocks via snap-fit assembly. It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP66. It has a metal bezel, this makes it Ideal for applications requiring high impact and vibration resistance. It is designed to fit in a standard 22mm cutout, ensuring compatibility when installing in pre-existing machinery. Its wide range of operating temperatures from -40°C to 70°C allows versatility in usage of product.
- Ambient Air Temperature For Storage:
- -40-70 °C
- Reach Regulation:
- Free of Substances of Very High Concern above the threshold
- Bezel Material:
- chromium plated metal
- Shape Of Signaling Unit Head:
- round
- Standards:
- IEC 60947-1 || JIS C8201-5-1 || UL 508 || IEC 60947-5-1 || IEC 60947-5-4 || CSA C22.2 No 14 || IEC 60947-5-5 || JIS C8201-1
- Electrical Composition Code:
- C1 9 single front mounting || C2 9 single and double front mounting || C11 3 single front mounting || C15 1 single front mounting
- Vibration Resistance:
- 5 gn 2-500 Hz)IEC 60068-2-6
- Overvoltage Category:
- class I IEC 60536
- Type Of Operator:
- spring return
- Protective Treatment:
- TH
- Mounting Diameter:
- 22 mm
- Mercury Free:
- Yes
- Product Or Component Type:
- head for non-illuminated push-button
- China Rohs Regulation:
- X
- Environmental Disclosure:
- ENVPEP1808008EN
- Range Of Product:
- Harmony XB4
- Sale Per Indivisible Quantity:
- 1
- Head Type:
- standard
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Nema Degree Of Protection:
- NEMA 13 || NEMA 4X
- Ambient Air Temperature For Operation:
- -40-70 °C
- Ik Degree Of Protection:
- IK06 IEC 50102
- Cad Overall Height:
- 29 mm
- Toxic Heavy Metal Free:
- Yes
- Rohs Exemption Information:
- Yes
- Reach Free Of Svhc:
- Yes
- Cad Overall Width:
- 29 mm
- Circularity Profile:
- ENVEOLI1808008EN
- Sustainable Offer Status:
- Green Premium product
- Mechanical Durability:
- 10000000 cycles
- Device Short Name:
- ZB4
- Ip Degree Of Protection:
- IP66 IEC 60529 || IP67 || IP69 || IP69K
- Product Certifications:
- BV || GL || CSA || DNV || LROS (Lloyds register of shipping) || UL Listed
- Warranty:
- 18 months
- Operator Profile:
- without cap
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- Cad Overall Depth:
- 28 mm
- Shock Resistance:
- 30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
