Schneider Electric ZB4BV043 Pilot Light Head
Schneider Electric
$5.59
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
This Harmony XB4, plain lens head for pilot light with universal LED is red. This head for universal LED pilot light is designed to last without maintenance for a bright indicator of process and machine operations. It is clearly distinguishable visually at a distance thanks to a clear color of len, enabling complex machine statuses to be read at a glance. It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP66. It has a metal bezel, this makes it Ideal for applications requiring high impact and vibration resistance. It is designed to fit in a standard 22mm cutout, ensuring compatibility when installing in pre-existing machinery. Its wide range of operating temperatures from -40°C to 70°C allows versatility in usage of product. A complete set of accessories to provide a solution for applications where exposure to high pressure cleaning, dust and extreme temperatures is an everyday occurrence. These harmony 22mm push buttons are used by machine manufacturers (automotive, textiles, timber) and control system panel builders. Certified and approved for meeting requirements throughout all continents: EN/IEC, UL, NEMA, CSA, CCC, Gost, JIS and many more. They have UL and CE markings and have ratings up to IP66 and IP69K.
- Resistance To High Pressure Washer:
- 7000000 Pa 55 °C 0.1 m
- Protective Treatment:
- TH
- Toxic Heavy Metal Free:
- Yes
- Product Compatibility:
- universal LED
- Cad Overall Height:
- 29 mm
- Range Of Product:
- Harmony XB4
- Net Weight:
- 0.026 kg
- China Rohs Regulation:
- X
- Sustainable Offer Status:
- Green Premium product
- Bezel Material:
- chromium plated metal
- Electrical Composition Code:
- P1 front mounting integral LED || P2 front mounting integral LED and transformer
- Reach Free Of Svhc:
- Yes
- Product Or Component Type:
- head for pilot light
- Device Short Name:
- ZB4
- Cad Overall Depth:
- 30 mm
- Cap/Operator Or Lens Colour:
- red
- Shock Resistance:
- 30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
- Ik Degree Of Protection:
- IK06 IEC 50102
- Sale Per Indivisible Quantity:
- 1
- Ambient Air Temperature For Storage:
- -40-70 °C
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Circularity Profile:
- ENVEOLI2308026EN
- Device Presentation:
- basic element
- Overvoltage Category:
- class I IEC 60536
- Operator Additional Information:
- with plain lens
- Standards:
- EN/IEC 60947-5-1 || EN/IEC 60947-5-4 || UL 508 || EN/IEC 60947-5-5 || JIS C8201-5-1 || CSA C22.2 No 14 || EN/IEC 60947-1 || JIS C8201-1
- Ip Degree Of Protection:
- IP66 IEC 60529 || IP67 || IP69 || IP69K
- Shape Of Signaling Unit Head:
- round
- Mercury Free:
- Yes
- Mounting Diameter:
- 22 mm
- Cad Overall Width:
- 29 mm
- Nema Degree Of Protection:
- NEMA 13 || NEMA 4X
- Warranty:
- 18 months
- Important Message:
- A change in appearance may be noted on the product but does not affect its use in terms of function and safety. This makes it compatible with our Universal LED blocks
- Rohs Exemption Information:
- Yes
- Ambient Air Temperature For Operation:
- -40-70 °C
- Reach Regulation:
- Free of Substances of Very High Concern above the threshold
- Vibration Resistance:
- 5 gn 2-500 Hz)IEC 60068-2-6
- Environmental Disclosure:
- ENVPEP2308026EN
- Head Type:
- standard
