Schneider Electric ZB5AA46 Pushbutton Operator Head
Schneider Electric
$35.50
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
This red button head provides a robust and ergonomic interface for controlling your machines thanks to its recessed high guard head. It is easily installed and replaced on compatible complete push button units and contact blocks via snap-fit assembly. It is clearly distinguishable visually at a distance thanks to its clear color. It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP66. It makes it ideal for operation in harsh environments.
- Shock Resistance:
- 30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
- Station Name:
- XALD 1...5 cut-outs || XALK 2...5 cut-outs
- Product Certifications:
- BV || LROS (Lloyds register of shipping) || CSA || DNV || GL || UL Listed
- Mercury Free:
- Yes
- Shape Of Signaling Unit Head:
- round
- Ik Degree Of Protection:
- IK03 IEC 50102
- Head Type:
- standard
- Cad Overall Height:
- 29 mm
- Standards:
- EN/IEC 60947-5-1 || CSA C22.2 No 14 || EN/IEC 60947-5-4 || JIS C8201-5-1 || UL 508 || EN/IEC 60947-1 || JIS C8201-1
- Sustainable Offer Status:
- Green Premium product
- Cad Overall Depth:
- 31 mm
- Environmental Disclosure:
- ENVPEP1710010EN
- Type Of Operator:
- spring return
- Overvoltage Category:
- class II IEC 60536
- China Rohs Regulation:
- X
- Mounting Diameter:
- 22 mm
- Circularity Profile:
- ENVEOLI1710010EN
- Device Short Name:
- ZB5
- Mechanical Durability:
- 10000000 cycles
- Ambient Air Temperature For Storage:
- -40-70 °C
- Device Presentation:
- basic element
- Net Weight:
- 0.02 kg
- Operator Additional Information:
- high guard
- Ip Degree Of Protection:
- IP66 IEC 60529 || IP67 || IP69 || IP69K
- Range Of Product:
- Harmony XB5
- Ambient Air Temperature For Operation:
- -40-70 °C
- Nema Degree Of Protection:
- NEMA 13 || NEMA 4X
- Product Or Component Type:
- head for non-illuminated push-button
- Warranty:
- 18 months
- Operator Profile:
- red recessed, unmarked
- Rohs Exemption Information:
- Yes
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Vibration Resistance:
- 5 gn 2-500 Hz)IEC 60068-2-6
- Resistance To High Pressure Washer:
- 7000000 Pa 55 °C 0.1 m
- Bezel Material:
- dark grey plastic
- Protective Treatment:
- TH
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Sale Per Indivisible Quantity:
- 1
- Electrical Composition Code:
- C1 9 single front mounting || C2 9 single and double front mounting || C11 3 single front mounting || C15 1 single front mounting || SF1 3 single front mounting || SR1 3 single rear mounting
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- Cad Overall Width:
- 29 mm
