Schneider Electric ZB5FA5C0 Flush Mounted Yellow Flush Caps Pb Head
Schneider Electric
$9.03
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
This 30.5 mm push-button head provides an ergonomic interface for controlling your machine. It is easily installed and replaced on compatible complete push-button units and contact blocks via snap-fit assembly. It is clearly distinguishable visually at a distance thanks to its clear color. It is vibration resistant, impact resistant, high pressure washer resistant and dust resistant thanks to its IP67, IP66 protection, making it ideal for operation in harsh environments.
- Overvoltage Category:
- class II IEC 60536
- Product Or Component Type:
- head for non-illuminated push-button
- Net Weight:
- 0.03 kg
- Warranty:
- 18 months
- Ambient Air Temperature For Storage:
- -40-70 °C
- Cad Overall Depth:
- 30 mm
- Ik Degree Of Protection:
- IK03 IEC 50102
- Mechanical Durability:
- 10000000 cycles
- Protective Treatment:
- TH
- Product Certifications:
- CSA || BV || LROS (Lloyds register of shipping) || DNV || GL || UL Listed
- Head Type:
- built-in-flush
- Shock Resistance:
- 30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27 || 25 gn 6 ms) 1000 shocks on each axis IEC 60068-2-27
- Cad Overall Height:
- 37 mm
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- Ip Degree Of Protection:
- IP66 IEC 60529 || IP67 IEC 60529
- Resistance To High Pressure Washer:
- 7000000 Pa 55 °C 0.1 m
- Type Of Operator:
- spring return
- Shape Of Signaling Unit Head:
- round
- Mounting Diameter:
- 30.5 mm
- Rohs Exemption Information:
- Yes
- Range Of Product:
- Harmony XB5
- Operator Profile:
- yellow flush, unmarked
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Bezel Material:
- plastic colour plated grey
- Mercury Free:
- Yes
- Product Compatibility:
- ZBYF... || ZBZF32 || ZBZF33 || ZB5AZ
- Vibration Resistance:
- 5 gn 10-500 Hz)IEC 60068-2-6 || 2 mm peak to peak 2-10 Hz)IEC 60068-2-6
- China Rohs Regulation:
- X
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Cad Overall Width:
- 37 mm
- Electrical Composition Code:
- C1 9 single front mounting || C2 9 single and double front mounting || C11 3 single front mounting || C15 1 single front mounting || SF1 3 single front mounting
- Ambient Air Temperature For Operation:
- -40-70 °C
- Device Short Name:
- ZB5
- Device Presentation:
- basic element
- Sale Per Indivisible Quantity:
- 1
- Datasheet:
- View
