SMC RSDG50-25B RSG Stopper Cylinder, Adjustable Mounting Height, 50mm Bore, 25mm Stroke, Double Acting, Spring Loaded, Round Bar
SMC
$115.40
SMC RSDG50-25B RSG Adjustable Mounting Height Stopper Cylinder
The SMC RSDG50-25B is a adjustable mounting height RSG stopper cylinder with a 50mm bore, 25mm stroke, double acting, spring loaded operation, and a round bar rod end. Stopper cylinders rise into the path of a conveyor to stop and position workpieces or pallets, then retract to release them.
Specifications
| Series | RSG |
| Type | Adjustable Mounting Height Stopper Cylinder |
| Bore Size | 50mm |
| Stroke | 25mm |
| Action | Double Acting, Spring Loaded |
| Rod End | Round Bar |
| Port Thread | Rc |
| Built-in Magnet | Yes (auto switch capable) |
| Weight | 2.95 lb |
RSG Series Highlights
- Mounting height can be raised or lowered to suit the distance to the workpiece
- Round bar, chamfered, roller, and lever rod end styles
- Double acting and single acting versions
- Auto switch capable on RSDG models (built-in magnet)
Need help confirming a part number, auto switch, or replacement? Contact Automation Distribution and our team will help.
- Series:
- RSG
- Bore Size:
- 50mm
- Cylinder Stroke:
- 25mm
- Action:
- Double Acting with Spring Loaded
- Piston rod end type:
- Round Bar
- Mounting Style:
- Flange (Adjustable Height)
- Port Thread Type:
- Rc
- With Auto Switch(Built-in Magnet):
- Yes
- Auto Switch:
- None
- Number Of Auto Switches:
- None
- Mounting Bolt:
- None
- Made To Order:
- Standard
