SMC SQ2140N-5LO1-C4 4/5 Port Solenoid Valve

SQ2*4*, 2000 Series, 5 Port Solenoid Valve, Plug Lead Type, New

The 5 port solenoid valves series SQ was designed for applications which demand high speed, high frequency, long life and a precise response time. The SQ uses cassette style valves and manifolds, making it simple to increase or decrease the number of stations on a DIN rail. Valves are available with 12VDC or 24VDC rated voltage. Actuation options include 5 port single solenoid, 5 port double solenoid, and dual 3/2 ported. Manifold variations for the SQ plug-in series include EX510 Gateway-type serial transmission system, D-sub connector, flat ribbon cable connector, PC wiring system compatible flat ribbon cable, terminal block box, or a lead wire kit. The SQ plug lead units are available with D-sub connector, flat ribbon cable connector or PC wiring system compatible flat ribbon cable kits.

- Fluid: Air/inert gas
- Maximum operating pressure: 0.7MPa
- Effective area mm 0.4W DC (34mA)
- Ambient fluid temperature: -10 to 50 C
