Turck Ni3.5-Q5.5-Rp6X-0.3-Vsg3M Inductive 4613679

(No reviews yet) Write a Review
SKU:
NI3.5-Q5.5-RP6X-0.3-VSG3M
Condition:
New
eCl@ss-Code (V5.1.4)::
27270101 -/- Inductive proximity switch
Design:
Rectangular
Construction size:
28 x 8 x 5.5 mm, Q5.5
Rated switching distance:
3.5 mm
Mounting:
Non-flush
Operating voltage:
10…30 VDC
Output function:
NC contact, PNP
Switching frequency:
2.0 kHz
Electrical connection:
Cable with connector, M5 × 0.5
Cable length (L):
0.30 m
Housing material:
Plastic, PP-GF20
Ambient temperature:
-25…+70 °C
Protection class:
IP67
$106.50

Description

Inductive Sensor, Rectangular, height 5.5 mm, Active face on top, Plastic, PP, DC 3-wire, 1030 VDC, Normally closed, PNP output, Pigtail with M5 connector, Cable length (L) 0.3ÿm, Rated switching distance: 3.5 mm, Non-flush
