WAGO 2000-1206 2-Conductor Through Terminal Block; 1 mm²; Ex e II; Side & Center Marking; DIN-Rail 35 x 15 & 35 x 7.5; Push-in CAGE CLAMP; Yellow
Wago
$1.76
TOPJOBS feedthrough terminal block; rail mount; 2-conductor; 3.5 mm wide; yellow.
The WAGO 2000 TOPJOB S series feed-through terminal block is a yellow, single-deck component designed for Ex e II applications. It features side and center marking slots and accommodates one feed-through pole with two push-in wire connections. The terminal block supports a nominal cross-section of 1mm² and is compatible with wire sizes ranging from 0.14mm² to 1.5mm² or #24AWG to #16AWG. It has a rated current of 13.5A or 17.5A and utilizes Push-in CAGE CLAMP spring connections. The unit mounts on a DIN-35 rail with dimensions of 35 x 15 or 35 x 7.5 and has a width of 3.5mm, equivalent to model 20001206.
- color:
- Gray
- country of origin sales organisation germany:
- CN
- depth:
- 33.5 mm / 1.319 inch
- fire load:
- 0.071 MJ
- flammability class per ul94:
- V0
- height:
- 67.2 mm / 2.646 inch
- packaging type:
- Box
- weight:
- 2.360 g
- width:
- 1 mm / 0.039 inch
