WAGO 222-412/K194-4045
- SKU:
- 222-412/K194-4045
- Condition:
- New
- Availability:
- In our warehouse: 2
- bounce time typ:
- 3.5 ms
- contact material relay:
- AgNi + Au
- country of origin sales organisation germany:
- DE
- depth:
- 28 mm / 1.09 inch
- dielectric strength control load circuit ac 1 min:
- 4 kVrms
- dielectric strength open contact ac 1 min:
- 1 kVrms
- drop out time typ:
- 4 ms
- electrical life no resistive load 23 c:
- 50 x 103 switching operations
- fire load:
- 0.071 MJ
- height from the surface:
- 15 mm / 0.591 inch
- inrush current resistive max:
- (AC) 20 A / 0.02 s
- limiting continuous current:
- 0.25
- mechanical life:
- 5 x 106 switching operations
- mounting type:
- Pluggable module
- nominal input voltage un:
- DC 24 V
- note:
- The 60 VDC basic relay must be used for 60 VDC, 110 VDC, 220 VDC and 115 VAC/DC, 230 VAC/DC relay modules.To protect the relay coils and contacts, inductive loads must be dampened with an effective protection circuit.30 VDC switching voltages and 50
- number of changeover switchover contacts:
- 1
- packaging type:
- Box
- protection type:
- IP20
- pull in time typ:
- 8 ms
- recommended minimum load:
- 1 V / 1 mA / 1 mW
- relative humidity:
- 5 85 % (no condensation permissible)
- standards specifications:
- EN 61810-1 || EN 61373 || VDE || UR
- surrounding air temperature operation at un:
- -40 85 C
- surrounding air temperature storage:
- -40 85 C
- switching capacity:
- AC-15: 3 A / AC 250 V: DC-13: 2 A / DC 24 V
- switching frequency with without load max:
- 6 min-1 / 180 min-1
- switching power resistive max:
- AC 1500 VA: DC (see load limit curve)
- switching voltage max:
- AC 250 V
- weight:
- 6.435 g
- width:
- 5 mm / 0.197 inch
Description
CLASSIC Splicing Connectorfor all conductor types, gray, 50 piece box
View AllClose
Electrical Data
- Rated voltage (II / 2): 400 V
- Rated impulse voltage (II / 2): 4 kV
- Rated current: 32 A
- Legend (ratings): (II / 2) Overvoltage category II / Pollution degree 2
Connection Data
- Connection technology: CAGE CLAMP<sup></sup>
- Actuation type: Lever
- Connectable conductor materials: Copper
- Solid conductor: 0.08 2.5 mm / 28 12 AWG
- Stranded conductor: 0.08 2.5 mm / 28 12 AWG
- Fine-stranded conductor: 0.08 4 mm / 28 12 AWG
- Strip length: 9 10 mm / 0.35 0.39 inch
- Total number of connection points: 2
- Total number of potentials: 1
- Type of wiring: Side-entry wiring
Geometrical Data
- Width: 12.4 mm / 0.488 inch
- Height: 14.5 mm / 0.571 inch
- Depth: 20.5 mm / 0.807 inch
Material Data
- Color: gray
- Flammability class per UL94: V0
- Fire load: 0.067 MJ
- Weight: 3.053 g
Environmental Requirements
- Surrounding air (operating) temperature: 40 C
- Continuous operating temperature: 85 C
Commercial data
- Packaging type: BOX
- Country of origin: DE
- GTIN: 4050821346470
- Customs Tariff No.: 85369010000
