WAGO 231-103/102-000
- SKU:
- 231-103/102-000
- Condition:
- New
- Availability:
- In our warehouse: 50
- color:
- Gray
- connection technology:
- CAGE CLAMP
- country of origin sales organisation germany:
- DE
- depth from upper edge of din rail:
- 28 mm / 1.102 inch
- fine stranded conductor:
- 0.08 2.5 mm / 28 14 AWG
- fire load:
- 0.764 MJ
- height:
- 73 mm / 2.874 inch
- mounting type:
- DIN-35 rail
- number of connection types:
- 4
- packaging type:
- Box
- pollution degree:
- 3
- rated continuous current:
- 0.416666666666667
- rated surge voltage:
- 6 kV
- rated voltage:
- 400 V
- solid conductor:
- 0.08 2.5 mm / 28 14 AWG
- strip length:
- 8 9 mm / 0.31 0.35 inch
- total number of potentials:
- 2
- weight:
- 43.650 g
- width:
- 27 mm / 1.063 inch
- wiring direction:
- Front-entry wiring
Description
Female plug; 3-pole; with integrated end plate; 12 AWG max; pin spacing 5 mm; 1 conductor per pole; gray
