Additional Information
actuation type: |
Operating tool |
color: |
Yellow |
connectable conductor materials: |
Copper |
connection technology: |
CAGE CLAMP® |
COUNTRY OF ORIGIN VKORG GERMANY: |
DE |
CUSTOMS TARIFF NUMBER VKORG GERMANY: |
85369010000 |
DEPTH FROM UPPER EDGE OF DIN RAIL: |
37.5 mm / 1.476 inches |
FINE STRANDED CONDUCTOR: |
0.2 ¢¦ 16 mm² / 24 ¢¦ 6 AWG |
FIRE LOAD: |
0.534 MJ |
FLAMMABILITY CLASS PER UL94: |
V0 |
HEIGHT: |
94.5 mm / 3.72 inches |
INSULATION MATERIAL: |
Polyamide (PA66) |
LEGEND RATINGS: |
(III / 3) ¢ Overvoltage category III / Pollution degree 3 |
MARKING LEVEL: |
Center marking |
MATERIAL GROUP: |
I |
MEASUREMENT ERROR DEVIATION MAX FROM THE UPPER RANGE VALUE: |
MEASUREMENT ERROR DEVIATION MAX OF THE UPPER RANGE VALUE 2= |
MISMATING PROTECTION: |
MOUNTING NOTE= |
MOUNTING TYPE: |
DIN-35 rail |
NOMINAL VOLTAGE III 3: |
800 V |
NOTE MATERIAL DATA: |
Information on material data can be found here |
POWER LOSS PER POLE POTENTIAL: |
2.4259 W |
PROCESSING TEMPERATURE: |
-35 ¢¦ +85 °C |
PRODUCT GROUP CODE: |
1 |
RATED CURRENT: |
76 A |
RATED CURRENT IN FOR SPECIFIED POWER LOSS: |
76 A |
RATED IMPULSE VOLTAGE III 3: |
8 kV |
RATINGS PER: |
IEC/EN 60947-7-1 |
RESISTANCE VALUE FOR SPECIFIED CURRENT DEPENDENT POWER LOSS: |
0.00042 © |
SOLID CONDUCTOR: |
0.2 ¢¦ 16 mm² / 24 ¢¦ 6 AWG |
STRIP LENGTH: |
16 ¢¦ 17 mm / 0.63 ¢¦ 0.67 inches |
WEIGHT: |
35.600 g |
WIDTH: |
12 mm / 0.472 inches |
WIRING DIRECTION: |
Front-entry wiring |
