Additional Information
actuation type: |
Operating tool |
color: |
Orange |
connectable conductor materials: |
Copper |
connection technology: |
CAGE CLAMP |
country of origin sales organisation germany: |
DE |
depth from upper edge of din rail: |
44.5 mm / 1.752 inch |
design: |
Horizontal type |
fine stranded conductor: |
0.08 1.5 mm / 28 16 AWG |
fire load: |
0.562 MJ |
flammability class per ul94: |
V0 |
height: |
126 mm / 4.961 inch |
insulation material: |
Polyamide (PA66) |
legend ratings: |
(III / 3) Overvoltage category III / Pollution degree 3 |
marking: |
Plain |
marking level: |
Center marking |
mounting type: |
DIN-35 rail |
nominal voltage iii 3: |
250 V |
packaging type: |
Box |
rated current: |
18 A |
rated surge voltage iii 3: |
4 kV |
solid conductor: |
0.08 1.5 mm / 28 16 AWG |
strip length: |
8 10 mm / 0.31 0.39 inch |
weight: |
29.986 g |
width: |
7.62 mm / 0.3 inch |
wiring direction: |
Front-entry wiring |
