WAGO 750-347

(No reviews yet) Write a Review

Write a Review

WAGO 750-347

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

750-347

UPC:

MPN:

750-347

Condition:

New

baud rate:

10 kBd 1 MBd

bus segment length max:

1000 m

cob id distribution:

SDO, standard

color:

Light gray

communication:

CANopen

communication profile:

DS-301 V4.1

conformity marking:

CE

connection technology communication fieldbus:

CANopen: 1 x Male connector: 5-pole

connection technology device configuration:

1 x Male connector: 4-pole

connection technology system supply:

4 x CAGE CLAMP

connection type 1:

System supply

country of origin sales organisation germany:

DE

depth:

71.9 mm / 2.831 inch

depth from upper edge of din rail:

64.7 mm / 2.547 inch

device profile:

DS-401 V2.0 || Configurable response in the event of an error

emc emission of interference:

Per EN 61000-6-4, marine applications

emc immunity to interference:

Per EN 61000-6-2, marine applications

exposure to pollutants:

Per IEC 60068-2-42 and IEC 60068-2-43

fine stranded conductor:

0.08 1.5 mm / 28 16 AWG

fire load:

3.280 MJ

height:

96.8 mm / 3.811 inch

housing material:

Polycarbonate: polyamide 6.6

input and output fieldbus process image max:

32 Byte/32 Byte

input current typ at nominal load 24 v:

260 mA

mounting position:

Horizontal (standing/lying): vertical

mounting type:

DIN-35 rail

node id distribution:

DIP switch

note:

Note: Configuration files required (EDS)!

note conductor cross section:

14 AWG: THHN, THWN

number of fieldbus nodes on master max:

110

number of modules per node max:

64

number of pdos:

5 Tx / 5 Rx

number of sdos:

1 SDO server

operating altitude:

0 2000 m

other canopen features:

NMT slave || Minimum boot-up || Variable PDO mapping || Emergency message || Life guarding

packaging type:

Box

permissible h2s contaminant concentration at a relative humidity 75:

10 ppm

permissible so2 contaminant concentration at a relative humidity 75:

25 ppm

pollution degree 5:

2 per IEC 61131-2

power consumption 5 v system supply:

350 mA

power supply efficiency typ at nominal load 24 v:

0.8

protection type:

IP20

relative humidity without condensation:

0.95

shock resistance:

15g per IEC 60068-2-27

solid conductor:

0.08 1.5 mm / 28 16 AWG

strip length:

5 6 mm / 0.2 0.24 inch

supply voltage system:

24 VDC (-25 +30 %): via pluggable connector

surrounding air temperature operation:

0 55 C

surrounding air temperature storage:

-40 85 C

total current system supply:

650 mA

transmission medium:

Shielded Cu cable 3 x 0.25 mm

vibration resistance:

4g per IEC 60068-2-6

weight:

135.000 g

width:

49.5 mm / 1.949 inch
