WAGO 750-979/000-013

(No reviews yet) Write a Review

Write a Review

×

WAGO 750-979/000-013

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

750-979/000-013

Condition:

New

cable connection direction note:

Selectable position

cable connection direction to mating direction:

90

code:

PROFINET

communication fieldbus:

PROFINET

connectable sheathed cable diameter:

5.5 10 mm

connection requirement permissible cable type:

Cat. 6A

connection type:

RJ-45 plug

connection type 1:

IDC contact

country of origin sales organisation germany:

TW

depth:

45.7 mm

fire load:

0.000 MJ

height:

41 mm

housing material:

Zinc die casting

packaging type:

Bag

pole no:

8

protection type:

IP20

relative humidity without condensation:

0.95

solid conductor:

0.21 0.32 mm / 24/1 22/1 AWG

standards specifications:

IEC60603-7-51, ISO/IEC 11801, IEEE 802.3an || EIA/TIA 568-C.2 || DIN EN 50173-1 || UL 1863 || UL 2043

stranded conductor 2:

0.11 0.36 mm / 27/7 22/7 AWG

surrounding air temperature operation:

-40 85 C

surrounding air temperature storage:

-40 85 C

weight:

26.000 g

width:

13.9 mm
