WAGO 757-383
- SKU:
- 757-383
- Condition:
- New
- Availability:
- In our warehouse: 15
- connection technology inputs outputs:
- 8 x M8 socket: 3-pole
- connection technology trunk cable:
- 1 x M16 plug: 14-pole
- contact resistance max:
- 0.01
- country of origin sales organisation germany:
- DE
- depth:
- 152 mm / 5.984 inch
- encapsulation:
- Fully encapsulated with conformal coating (UL 94 V0)
- halogen free:
- Yes
- height:
- 26 mm / 1.024 inch
- housing material:
- PA 66 (UL 94 V0): RAL 7035: silicon and halogen free
- indicators:
- LED yellow: Signal status (1 x per contact): LED (U) green: Sensor/actuator box status
- insulation resistance:
- 1000 M
- material properties of the connections:
- Contact: CuSn, nickel base-coat plating and 0.8 m gold-plated: Threaded bush: die-cast Zn, nickel-plated: Seal: Viton: 50 mating cycles
- mounting type:
- Screw mount
- note on protection type:
- Per EN 60529 (NEMA 6 & 6P) in the fully locked position with its plugs or protective caps
- packaging type:
- Box
- pollution degree 5:
- 3 per VDE 0110
- protection type:
- IP67
- rated value of electrical isolation:
- 500 V
- shock resistance:
- Per IEC 60068-2-27
- signal characteristic:
- PNP
- supply voltage:
- 10 30 VDC: Rated voltage: 32 V ~ rms
- surrounding air temperature operation:
- -25 80 C
- vibration resistance:
- Per IEC 60068-2-6
- width:
- 30 mm / 1.181 inch
Description
M8 sensor/actuator box; 8-way; 3-pole; M16 connector
View AllClose
- M8 sensor/actuator box, 8-way
- 3-pole (1 signal per contact)
- M16 connector (14ole)
- Green LED operating indicator
- Yellow LED status indicator
- incl. marker strips (note: WMB markers can also be used)
- incl. M8 protective caps (2 pcs)
