Description
1-conductor female connector; CAGE CLAMP; 4 mm²; Pin spacing 5 mm; 13-pole; coding finger; 4,00 mm²; blue
View AllClose
Additional Information
actuation type: |
Operating tool |
color: |
Blue |
connectable conductor materials: |
Copper |
connection technology: |
CAGE CLAMP |
connector connection type: |
For conductor |
contact type pluggable connector: |
Female connector/socket |
country of origin sales organisation germany: |
DE |
depth: |
18.3 mm / 0.72 inch |
fine stranded conductor: |
0.08 4 mm / 28 12 AWG |
fire load: |
0.736 MJ |
flammability class per ul94: |
V0 |
height: |
45.2 mm / 1.78 inch |
insulation material: |
Polyamide (PA66) |
legend ratings: |
(III / 3) Overvoltage category III / Pollution degree 3 |
marking level: |
Side marking |
module width: |
5 mm / 0.197 inch |
nominal cross section: |
4 mm |
nominal voltage iii 3: |
500 V |
packaging type: |
Box |
pole no: |
13 |
rated current: |
32 A |
rated surge voltage iii 3: |
6 kV |
ratings per: |
IEC/EN 61984 |
safety information 1: |
According to EN 61984, pluggable connectors without current interrupting capacity must not be mated or unmated when live or under load. |
solid conductor: |
0.08 4 mm / 28 12 AWG |
strip length: |
8 9 mm / 0.31 0.35 inch |
weight: |
42.513 g |
width: |
65 mm / 2.559 inch |
wiring direction: |
Front-entry wiring |
