LED (LINK/ACT) green: Network connection via ports 1 2: LED (MS, NS) red/green: Status of node, network: LED (I/O, USR) red/green/orange: Local data bus status, status programmable by user: LED (A, B) green: System power supply status, field su
input and output fieldbus process image max:
1020 Worte/1020 Worte
input current typ at nominal load 24 v:
500 mA
isolation:
500 V system/field
mounting position:
Any
mounting type:
DIN-35 rail
non volatile software memory:
32 kB
number of modules per node max:
250
number of modules without a bus extension max:
64
number of outgoing power jumper contacts:
3
operating altitude:
Without temperature derating: 0 2000 m: with temperature derating: 2000 5000 m (0.5 K/100 m): 5000 m (max.)
packaging type:
Box
permissible h2s contaminant concentration at a relative humidity 75:
10 ppm
permissible so2 contaminant concentration at a relative humidity 75:
25 ppm
pollution degree 5:
2 per IEC 61131-2
power consumption 5 v system supply:
450 mA
power supply efficiency typ at nominal load 24 v:
0.9
program memory:
1024 kByte
programming environment:
WAGO-I/O-PRO V2.3 (based on CODESYS V2.3)
programming languages per iec 61131 3:
Instruction List (IL) || Ladder Diagram (LD) || Function Block Diagram (FBD), Continuous Function Chart (CFC) || Structured Text (ST) || Sequential Function Chart (SFC)
