WAGO 769-609/004-000

(No reviews yet) Write a Review

SKU:: 769-609/004-000
Condition:: New
actuation type:: Operating tool
color:: Gray
connectable conductor materials:: Copper
connection technology:: CAGE CLAMP
connector connection type:: For conductor
contact type pluggable connector:: Male connector/plug
country of origin sales organisation germany:: PL
depth:: 40.2 mm / 1.583 inch
fine stranded conductor:: 0.08 4 mm / 28 12 AWG
fire load:: 0.560 MJ
flammability class per ul94:: V0
height from the surface:: 18.3 mm / 0.72 inch
insulation material:: Polyamide (PA66)
legend ratings:: (III / 3) Overvoltage category III / Pollution degree 3
mounting type:: Feedthrough flange
nominal cross section:: 4 mm
nominal voltage iii 3:: 500 V
packaging type:: Box
pin spacing:: 5 mm / 0.197 inch
pole no:: 9
rated current:: 32 A
rated surge voltage iii 3:: 6 kV
solid conductor:: 0.08 4 mm / 28 12 AWG
strip length:: 8 9 mm / 0.31 0.35 inch
weight:: 27.683 g
width:: 59.7 mm / 2.35 inch
wiring direction:: Front-entry wiring

$13.31

Current Stock:

Quantity:

Description

Description

Description

Male connector; with CAGE CLAMP connection and feedthrough flanges; for screw or similar mounting types; for parallel or perpendicular mounting; Pin spacing 5 mm / 0.197 in; 9-pole

Remarks

Item properties

Miscellaneous

Name	Value	Unit
No. of poles	9
Pin spacing	5 mm / 0.197 in
Total number of connection points	9
Total number of potentials	9
Color	gray
Rated voltage (III / 3) [V]	500	V
Rated impulse voltage (III / 3) [kV]	6	kV
Rated current [A]	32	A
Connection technology	CAGE CLAMP
Number of connection points connector	1
Actuation type	Operating tool
Connectable conductor materials	Copper
Nominal cross section	4 mm nbsp;
Solid conductor	0.08 4 mm / 28 12 AWG
Fine-stranded conductor	0.08 4 mm / 28 12 AWG
Strip length	8 9 mm / 0.31 0.35 Inch
Type of wiring	Front-entry wiring
Insulating material	Polyamide 66 (PA 66)
Fire load [MJ]	0.56	MJ
Weight [g]	27.238	g
Width	59.7 mm / 2.35 Inch
Height from the surface	18.3 mm / 0.72 Inch
Depth	40.2 mm / 1.583 Inch
Pin spacing from [mm]	5	mm
Mounting type	Mounting flange
